Floor-mounted electric cabinet B80-8005-A

free-standingindustrialfor electrical equipment

Overview
The SiS Li-Ion Basic battery cabinet from LaCont is an entry-level solution for active and passive storage and optional charging of lithium‑ion rechargeable batteries. The product prioritises fire protection and containment to limit the effects of a battery incident on people and the surrounding area.

Key features

• Certified complete structure with 90 minutes fire resistance for internal and external exposure (fire resistance class EI90, tested to EN 1363-1).
• Constructed from non-combustible building materials (Class A2 – s1, d0 according to DIN EN 13501-1); body in aluminium colour, doors in RAL 1023 (traffic yellow).
• Perimeter fire protection seals that automatically expand/foam in case of fire.
• Doors lockable with a double‑bit cylinder lock (swing lever).
• Integrated ventilation system with smoke detector and fan; mechanical ventilation and smoke detection are standard; ventilation shuts off automatically in the event of a fire.
• Fire‑resistant cable entries at top and bottom for retrofitting alarm wiring or power feeds.
• Smooth‑opening doors with 180° opening angle; doors are non‑self‑closing.
• Base with 100 mm clearance underneath for pallet truck/forklift access; removable base/plinth panel.
• Storage levels provided by height‑adjustable grating (load capacity 75 kg per shelf); standard number of grating levels: 4.
• Integrated floor pan (17 litres) to contain leaked liquids and prevent environmental contamination.
• Surge protection included as standard.

Options & accessories

• Optional integrated aerosol fire‑extinguishing generator that activates automatically in case of critical temperature rise or fire.
• Optional power strip(s) installed in the cabinet (used in Charge variants) enabling organised charging of multiple batteries simultaneously (configurable: 0 / 2 / 4 outlets).
• Optional control unit with fire detection and visual status indicator; control unit can provide a potential‑free contact for forwarding signals to a control centre.
• Optional active fire suppression system with power‑independent activation on fire or unauthorised temperature rise.

Certifications & conformity

• Fire resistance testing and certification in accordance with DIN EN 1363-1 / EN 1363-1.
• Certification/report documented by MPA Dresden.

Protection objectives

• Contain fire inside the cabinet to provide time for evacuation and initiation of firefighting measures.
• Protect stored batteries from external fire events and reduce risks from the stored goods to surrounding personnel and installations.

Technical specifications

• Model designation: SiS Li-Ion Basic (Basic Store / Basic Charge variants).
• Fire resistance class: EI90 (internal & external), tested to EN 1363-1.
• Internal fire resistance: 90 minutes (EN 1363-1).
• External fire resistance: 90 minutes (EN 1363-1).
• Test standard: DIN EN 1363-1:2012-10.
• Certification: Report by MPA Dresden.
• Recommended maximum stored energy: max. 8 kWh (for standard commercial batteries only).
• Maximum stored energy per VDMA 24994: not specified.
• Charging inside cabinet: optional (Charge variants).
• Number of charging points (configurable): 0 / 2 / 4.
• Maximum charging power per cabinet: 3.5 kW (note: some configurations limit to 2 kW per power strip).
• Integrated pressure relief: not provided as standard.
• Integrated mechanical ventilation: yes (standard).
• Self‑closing doors: no.
• Control unit: optional.
• Smoke detectors / fire detection: standard.
• Mechanical ventilation: standard; ventilation shuts off in event of fire.
• Visual and audible status indicators: visual optional; audible optional.
• Shutdown in emergency: ventilation only (standard).
• Active fire suppression: optional.
• Potential‑free interface (voltage‑free contact): yes.
• Cable entry possible: yes (top and bottom).
• Pre‑fitted cable for fire alarm: not standard.
• Locking system: swing lever with double‑bit cylinder.
• Number of grating floors: 4 (standard).
• Number of steel shelves, powder‑coated: 0 (standard).
• Load capacity per shelf: 75 kg.
• Base clearance for vehicle access: yes (100 mm).
• Floor pan capacity: 17 litres.
• Surge protection: yes (standard).
• Supply voltage: 230 V (typical fuse rating 16 A single‑phase for control unit / charge variants).
