Multitouch screen monitor W50L100-POCV

projected capacitive touchscreen50"3840 x 2160

Overview
The W50L100-POCV is a 50-inch curved multi-touch display for industrial visualization, control rooms and equipment monitoring. It delivers 4K resolution (3840 x 2160), R1500 curvature and Projected Capacitive touch for precise multi-touch interaction in integration and OEM environments.

Key Features

• 50-inch 3840 x 2160 4K panel
• Projected Capacitive Multi-Touch (P-Cap)
• Multiple video inputs: 2 x DisplayPort, 1 x HDMI, 1 x DVI
• USB port for touch interface
• VESA mounting support for integration

Highlights

• R1500 curved panel for expanded field of view
• Wide viewing angles with 10-bit color depth
• 60 Hz refresh rate for smooth motion
• Metal, fanless enclosure for vibration-free operation

Certifications

• CE
• FCC

Product Details
Display

• Touch / Glass: Projected Capacitive Multi Touch Screen
• Size: 50.0 inches
• Resolution: 3840 x 2160
• Panel Brightness: 425 nits
• Contrast Ratio: 4000:1
• View Angles: 89, 89, 89, 89
• Display Color: 10-bit Colors
• Active Area: 1068.84 x 616.4 mm

Environment

• Operating Humidity: 10% to 90% RH, non-condensing
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -10°C to 60°C

IO Ports

• 2 x DisplayPort
• 1 x HDMI
• 1 x DVI
• USB port for touch communication

Mechanical

• Dimensions (W x H x D): 1153 x 679 x 164 mm
• Mounting: VESA mount (standard holes)
• Enclosure: Metal
• Cooling System: Fanless design

Accessories

• 1 x USB cable
• 1 x HDMI cable
• 1 x DisplayPort cable
• 1 x DVI cable
• 100~240V AC to DC Adapter and power cord
• Manual and VESA screws (varies by product)

Power

• Power input: 24V DC

Control

• 7 Keys: Power, Menu, Down, Up, Left, Right, Exit

Technical Specifications

• Model: W50L100-POCV
• Display size: 50.0 inches
• Resolution: 3840 x 2160 (4K)
• Touch technology: Projected Capacitive Multi-Touch
• Brightness: 425 nits
• Contrast ratio: 4000:1
• Color depth: 10-bit
• Active area: 1068.84 x 616.4 mm
• Curvature: R1500
• Refresh rate: 60 Hz
• Video inputs: 2 x DP, 1 x HDMI, 1 x DVI
• Mounting: VESA
• Dimensions: 1153 x 679 x 164 mm
• Enclosure: Metal, fanless
• Operating temperature: 0°C to 50°C
• Storage temperature: -10°C to 60°C
• Operating humidity: 10% to 90% RH
• Power input: 24V DC
• Accessories included: USB, HDMI, DP, DVI cables; AC/DC adapter; power cord; manual; VESA screws
• Certifications: CE, FCC
