Piston compressor SC series
airelectrically-poweredstationary

piston compressor
piston compressor
piston compressor
piston compressor
piston compressor
Add to favorites
Compare this product


Characteristics

Technology
piston
Type
air
Power source
electrically-powered
Portability
stationary
Lubrication
oil-lubricated
Application domain
industrial
Other characteristics
compact, low-noise
Pressure

Min.: 0 bar
(0 psi)

Max.: 10 bar
(145.04 psi)

Flow

0.54 m³/min, 0.73 m³/min, 1.01 m³/min, 1.51 m³/min, 1.91 m³/min
(19.07 ft³/min, 25.78 ft³/min, 35.67 ft³/min, 53.33 ft³/min, 67.45 ft³/min)

Power

4 kW, 5.5 kW, 7.5 kW, 11 kW, 15 kW
(5.44 hp, 7.48 hp, 10.2 hp, 14.96 hp, 20.39 hp)

Length

830 mm
(33 in)

Width

1,570 mm
(62 in)

Height

1,120 mm
(44 in)

Weight

341 kg, 363 kg, 389 kg, 453 kg, 463 kg
(751.8 lb, 800.3 lb, 857.6 lb, 998.7 lb, 1,020.7 lb)

Description

The compact TOP AIR piston compressors combine the advantages of a reciprocating compressor in 10 and 15 bar versions with a modern control and monitoring system. Intelligent monitoring controls the compressed air generation and treatment, ensuring an extremely efficient, safe and quiet operation in an unbeatable compact format. Product Oil lubricated piston compressor, super-silenced Advantages designed for 100% duty cycle extremely quiet focus control 2.0
