Inductive proximity sensor CL12-RF2DN1-ScylindricalM12with switching function
Add to favorites
Compare this product
Characteristics
- Technology
- inductive
- Shape
- cylindrical
- Diameter
- M12
- Output signal
- with switching function, NPN
- Supply voltage
- DC, 24VDC, 12VDC
- Mounting
- flush
- Protection level
- IP67
- Other characteristics
- 3-wire
- Measuring range
Max.: 2 mm
(0.08 in)Min.: 0 mm
(0 in)- Process temperature
Max.: 80 °C
(176 °F)Min.: -40 °C
(-40 °F)
Description
Product overview
Technical specifications
Mechanical / Electrical parameters
Operating environment
Additional information
- Product name: CL12-RF2DN1/S
- Series: CL12 inductive proximity sensors
- Type: low-temperature inductive proximity sensor
- Sensing distance: 2 mm
- Housing: M12 cylindrical
- Detection principle: inductive
- Output: NPN normally open (NO)
Technical specifications
- Standard target: iron 12×12×1 mm
- Hysteresis: less than 10% of sensing distance
- Temperature drift: within ±15% over -40 to +80 °C (reference +23 °C)
- Response frequency/time: 800 Hz / 625 μs
- Accessories: 2 nuts, 1 tooth washer, inspection certificate
Mechanical / Electrical parameters
- Output: NPN NO
- Supply voltage: DC 12–24 V
- Wiring: 3-wire DC
- Ingress protection: IP67
- Connection: molded cable, length 2 m
- Signal type: switching
- Operating mode: normally open
- Mounting: flush
- Current consumption: <15 mA
- Indicator: yellow output LED
- Protection: short-circuit and surge protection
- Voltage influence: within ±1% detection change for ±15% supply variation
- Max load current: ≤100 mA
- Insulation resistance: ≥50 MΩ (DC 500 V)
- Dielectric strength: AC 1000 V 50/60 Hz 1 min
- Shock resistance: 500 m/s², 3 shocks each axis X/Y/Z
- Vibration resistance: 10–55 Hz, 1.5 mm double amplitude, 2 h each axis
- Weight: 65 g
Operating environment
- Operating temperature: -40 to +80 °C
Additional information
- Included drawings: wiring diagram for cylindrical molded-cable version and dimensional drawing for the low-temperature version
