Inductive proximity sensor CL12-RF2DP2-ScylindricalM12with switching function
Add to favorites
Compare this product
Characteristics
- Technology
- inductive
- Shape
- cylindrical
- Diameter
- M12
- Output signal
- PNP, with switching function
- Electrical connection
- bare wires
- Supply voltage
- DC, 24VDC, 12VDC
- Mounting
- flush
- Material
- brass, PVC, PTFE
- Applications
- industrial
- Other characteristics
- 3-wire
- Measuring range
Max.: 2 mm
(0.08 in)Min.: 0 mm
(0 in)- Process temperature
Max.: 80 °C
(176 °F)Min.: -40 °C
(-40 °F)
Description
Product overview
Technical specifications
Mechanical / Electrical parameters
Applicable environment
Characteristics / technical summary
- Model: CL12-RF2DP2/S
- Series: CL12 inductive proximity sensors
- Type: Low-temperature
- Sensing distance: 2 mm
- Body: Cylindrical (M12)
- Sensing principle: Inductive
- Output: PNP NC
- Size: M12
- Cable length: 2 m (molded cable)
Technical specifications
- Sensing direction: Face
- Operating frequency: 800 Hz
- Response time: 625 μs
- Detectable target: Metal
- Special feature: Low-temperature resistant
- Accessories: Nuts ×2, internal tooth washer ×1, certificate
- Hysteresis: <10% of sensing distance
- Standard test object: Iron 12×12×1 mm
- Temperature drift: Within ±15% of sensing distance between -40 and +80°C (reference +23°C)
- Materials: Housing: nickel-plated brass; sensing face: PTFE; cable: PVC
Mechanical / Electrical parameters
- Output type: PNP NC
- Supply voltage: DC 12–24 V
- Wiring: 3-wire DC
- Protection rating: IP67
- Connection: Molded cable
- Signal type: Switching
- Operating mode: Normally closed
- Mounting: Flush/embedded
- Current consumption: <15 mA
- Indicator: Yellow output LED
- Protection circuits: Short-circuit and surge protection
- Voltage influence: Within ±1% sensing distance change for ±15% supply voltage variation
- Load current: ≤100 mA
- Insulation resistance: ≥50 MΩ (DC 500 V megohmmeter) between live parts and housing
- Shock resistance: 500 m/s², 3 times each X, Y, Z
- Dielectric strength: AC 1000 V 50/60 Hz 1 min between live parts and housing
- Vibration resistance: 10–55 Hz double amplitude 1.5 mm, 2 h each X, Y, Z
- Weight: 65 g
Applicable environment
- Operating temperature: -40~+80°C
Characteristics / technical summary
- Model: CL12-RF2DP2/S
- Sensing distance: 2 mm
- Form factor: M12 cylindrical, flush mounting
- Detectable targets: Ferrous metals; standard test object: iron 12×12×1 mm
- Electrical: DC 12–24 V, 3-wire DC, PNP normally closed, load ≤100 mA
- Environment: Operating temperature -40~+80°C, IP67
- Materials: Nickel-plated brass housing, PTFE sensing face, PVC cable
- Accessories: Nuts ×2, internal tooth washer ×1, certificate
