Inductive proximity sensor CL12-RF2DN2-ScylindricalM12NPN
Add to favorites
Compare this product
Characteristics
- Technology
- inductive
- Shape
- cylindrical
- Diameter
- M12
- Output signal
- NPN
- Electrical connection
- bare wires
- Supply voltage
- 24VDC, 12VDC
- Mounting
- flush
- Material
- brass, PVC, PTFE
- Protection level
- heat/cold-resistant, IP67
- Applications
- industrial
- Other characteristics
- with LED light, 3-wire
- Measuring range
Min.: 0 mm
(0 in)Max.: 2 mm
(0.08 in)- Process temperature
Min.: -40 °C
(-40 °F)Max.: 80 °C
(176 °F)
Description
Product overview
Key specifications
Electrical & mechanical parameters
Materials & installation
Applications
- Series: CL12
- Model: CL12-RF2DN2/S
- Type: Low-temperature resistant inductive proximity sensor
- Detection distance: 2 mm
- Housing: cylindrical (M12)
- Detection principle: Inductive (for metal targets)
- Output: NPN NC (normally closed)
- Connection: molded cable, 2 m
Key specifications
- Detecting distance: 2 mm
- Standard detection object: Iron 12×12×1 mm
- Hysteresis: < 10% of detection distance
- Response frequency: 800 Hz
- Response time: 625 μs
- Operating temperature: -40 to 80 °C
- Temperature drift: within ±15% (reference +23 °C over -40~+80 °C)
- Protection rating: IP67
- Weight: 65 g
- Accessories: 2 nuts, 1 internal tooth washer, certificate
Electrical & mechanical parameters
- Supply voltage: DC 12–24 V
- Power supply: DC three-wire
- Output type: NPN NC
- Current consumption: < 15 mA
- Max load current: < 100 mA
- Indicator: yellow output LED
- Protection circuits: short-circuit and surge protection
- Insulation resistance: > 50 MΩ (DC 500 V)
- Dielectric strength: AC 1000 V 50/60 Hz 1 min
- Shock resistance: 500 m/s², 3 shocks per axis (X/Y/Z)
- Vibration resistance: 10–55 Hz, 1.5 mm double amplitude, 2 h per axis
Materials & installation
- Housing: nickel-plated brass
- Sensing face: Teflon
- Cable: PVC
- Mounting: flush (embedded) M12
- Connection: molded cable
Applications
- Detection of metal parts in automation, machinery and assembly lines
- Suitable for low-temperature environments down to -40 °C
- Recommended for front-face metal detection and embedded mounting
