Rotary vane vacuum pump SCP7

oil-lubricatedfor pharmaceutical applicationsfor laboratory

Overview
Driving most OINDP testing systems is the vacuum pump. The SCP7 is a super-capacity vacuum pump capable of providing very high unrestricted flow rates and sonic flow through the NGI, designed for DPI applications and as a viable alternative to using two HCP7 pumps.

Capabilities
Capable of generating sonic (P3/P2 ≤ 0.5) flow rates through the Next Generation Impactor (NGI) up to 100 L/min. Provides a maximum unregulated flow of 683 L/min, ideal for DPI applications. Can be used for MDI, nebuliser and nasal product testing via a flow control valve which regulates the flow rate between 0 and 280 L/min.

Key features

• Low maintenance
• Advanced sound insulation
• Oil-lubricated rotary vane
• Left and right vacuum inlets – choose where to place pump in system
• Dual filtration process ensures there is virtually no oil vapour in the exhaust air, making it suitable for use in a laboratory environment

SCP7 Vacuum Pump Technical Specifications (table)
Type: Rotary vane
Lubrication type: Oil
Max. flow in L/Min (unrestricted): 683
Max. sonic flow through NGI: 100
Max. vacuum level: <0.1 kPa
Applications: MDIs, DPIs, Nebulisers, ADIs, Nasal Products
Dimensions (w x d x h): 480 x 690 x 460 mm

Technical specifications

• Type: Rotary vane
• Lubrication type: Oil
• Max. flow (unrestricted): 683 L/min
• Max. sonic flow through NGI: 100 L/min
• Max. vacuum level: <0.1 kPa
• Applications: MDIs, DPIs, Nebulisers, ADIs, Nasal Products
• Dimensions (w x d x h): 480 x 690 x 460 mm
