NUC motherboard WLN51

Intel® Core™ i seriesIntel® Celeron® N3350Intel®

Product Overview

• Intel® 4”x4” NUC board dimension
• 8th Gen Intel® Core™ Processors
• DDR4 SODIMM: Single Channel DDR4 up to 32GB 2400 MHz
• Low Profile I/O Under 20mm: 1 GbE, 1 HDMI 2.0, 3 USB 3.1, 1 USB 2.0

Features

• Fanless Design
• DDR4 Memory Support
• Rich I/O Connectivity
• Powerful Processor

Technical Specifications
System
Processor: 8th Gen Intel® Core™ Processors
Intel® Celeron® Processor 4205U (2M Cache, 1.80 GHz) (formerly Whiskey Lake)
Chipset: Intel® Mobile Chipset
Memory: One SODIMM up to 4GB Single Channel DDR4 2400 MHz
BIOS: AMI SPI 128Mbit

Graphics
Controller: Intel® UHD Graphics
Feature: OpenGL 4.5, DirectX 12, OpenCL 2.1
HW Decode: MPEG2, WMV9, AVC/H264, JPEG/MJPEG, HEVC/H265, VP9, AV1
HW Encode: AVC/H264, JPEG, HEVC/H265, VP9
Display: 1 x mini HDMI 2.0b

Storage
Storage: 64GB eMMC

Audio
Audio Codec: Via HDMI

I/O
USB: 3 x USB 3.1, 1 x USB 2.0

Watchdog Timer
Output & Interval: System Reset, Programmable via Software from 1 to 255 Seconds

Security
TPM: Intel PTT (fTPM)

Power
Type: 12DC power input, 16 pin socket
Consumption: TBD

OS Support
Microsoft: Windows 10 IoT Enterprise

Environment
Temperature: Operating: 0 to 55°C, Storage: -40 to 85°C
Humidity: TBD
MTBF: TBD

Mechanism
Dimensions: 100mm x 100mm

Country of Origin
Country of Origin: Taiwan

Tags

• 8th Gen Intel® Core™ Processor
• Intel
• Fanless Design
• 1G Ethernet
• Windows
• 12V DC-in
• DDR4
• ULT

Key Characteristics / Technical Specifications

• Intel® 4”x4” NUC board dimension
• 8th Gen Intel® Core™ Processors
• DDR4 SODIMM: Single Channel DDR4 up to 32GB 2400 MHz
• Low Profile I/O Under 20mm: 1 GbE, 1 HDMI 2.0, 3 USB 3.1, 1 USB 2.0
• Fanless Design
• 64GB eMMC storage
• Intel® UHD Graphics
• Windows 10 IoT Enterprise support
• Dimensions: 100mm x 100mm
• Country of Origin: Taiwan
