Industrial drum vac Model 6303 Premium EasySwitch®

drywetliquids

Overview
The EasySwitch® Wet‑Dry Vac System P6301 (Premium kit) is a pneumatic, drum‑mounted vacuum designed for industrial wet and dry cleanup. It operates without electricity, uses minimal compressed air and rests on a standard 55 gallon open‑top drum. The patented EasySwitch filter hatch enables fast changeover between dry and liquid operation while an automatic float prevents drum overfill.

Applications

• Coolant recovery
• Metal chips and shavings
• Shop and floor cleanup
• Drain and sump cleaning
• Sawdust and wood shavings
• Absorbent material pickup
• Mold and allergen removal

Advantages

• Fast transition liquid↔dry via single‑latch filter hatch
• High vacuum performance with low compressed air consumption
• Low noise operation (~79 dBA typical)
• Maintenance‑free vacuum generator with no motors or moving parts
• Safe, non‑electrical operation for wet environments
• Automatic float shutoff to prevent spills
• Continuous duty and compatible with standard 55 gallon drums

Styles
The EasySwitch system is offered in Standard, Deluxe and Premium kits. The Standard kit provides the EasySwitch unit, drum lid, standard filter (HEPA optional), compressed air hose assembly, pressure gauge and basic tools. The Deluxe kit adds antistatic hose, drum dolly, spill recovery kit and expanded tool set. The Premium kit includes all Deluxe items plus a 55 gallon drum.

What's Included?

• EasySwitch Vac unit
• EasySwitch drum lid
• Standard filter or HEPA filter with pre‑filter
• 10' of 1‑1/2" (38 mm) antistatic hose
• Drum dolly (Deluxe & Premium)
• 1/2" compressed air hose assembly
• Pressure gauge
• Spill recovery kit
• Extension wand
• Round dust brush
• Skimmer tool
• 24" crevice tool
• 11" crevice tool
• 12" wide floor tool
• Tool holder

Performance
EasySwitch Wet‑Dry Vac Performance
Pressure Supply (PSIG / BAR) | Air Consumption (SCFM / SLPM) | Lift ("H2O / mm Hg) | Vacuum Flow (CFM / LPM) | Sound Level (dBA)
80 / 5.5 | 53 SCFM / 1,500 SLPM | -168" H2O / -314 mm Hg | 90 CFM / 2,548 LPM | 79 dBA
90 / 6.2 | 59 SCFM / 1,670 SLPM | -190" H2O / -355 mm Hg | 92 CFM / 2,605 LPM | 80 dBA
100 / 6.9 | 65 SCFM / 1,840 SLPM | -210" H2O / -392 mm Hg | 94 CFM / 2,661 LPM | 82 dBA

Conveying Rate Comparison (examples)
Pressure Supply (PSIG / BAR) | Water (GPM / LPM) | Plastic Tumbling Media (lbs/min / kg/min) | Steel Shot (lbs/min / kg/min)
80 / 5.5 | 36 GPM / 136 LPM | 68 lbs/min / 31 kg/min | 54 lbs/min / 24 kg/min

How It Works
The unit uses a single‑latch filter hatch: install the filter for dry pickup and remove it for liquid pickup. A float inside the drum stops suction when liquid reaches the shutoff level, preventing spills.

Safety / Warnings
Do not use with flammable or low‑flash‑point liquids (e.g., fuel oil, alcohol, mineral spirits, gasoline, kerosene). Do not use with combustible dust.

Specifications

• Brand: EXAIR
• Model / SKU: P6301
• Denomination: EasySwitch® Wet‑Dry Vac System
• Patent No.: 11,969,134
• Designed to rest on standard 55 gallon open‑top drums (Premium kit includes a 55 gallon drum)
• Power: Pneumatic — uses compressed air (no electricity required)
• Typical sound level: ~79 dBA (80–82 dBA depending on supply)
• Compressed air examples: 80 PSIG (5.5 BAR) → 53 SCFM (1,500 SLPM); 100 PSIG (6.9 BAR) → 65 SCFM (1,840 SLPM)
• Vacuum lift: up to -210" H2O (approx. -392 mm Hg) at 100 PSIG
• Vacuum flow: ~90–94 CFM (2,548–2,661 LPM) depending on supply
• Filter options: Standard or HEPA certified filter with pre‑filter for dry operation
• Automatic float shutoff to prevent spills when drum fills with liquid
• No motors or moving parts in vacuum generator — continuous duty and low maintenance
• Kits available: Standard, Deluxe (adds dolly, upgraded hose, more tools), Premium (Deluxe + 55 gallon drum)
