LED light module HM96-HE-4 series

Overview
High-efficiency 24 V LED module designed for uniform linear lighting. Prismatic lens with 160° viewing angle ensures wide diffusion; recommended installation thickness: 50 mm to 150 mm. 3M VHB adhesive with removal tab enables fast and secure mounting.

Key features

• Dimension: 90 x 15 mm
• Modules per chain: 40 pcs
• Fixing: 3M VHB adhesive with removal tab
• Consistent white light: < 3 SDCM
• Protection class: IP66/IP67
• Modules per packaging: 80 pcs

Available models
Model | Color | CCT | Luminous flux | Voltage | Power
HM96-HE-4W12 | White | 7000 K | 144 lm | 24 VDC | 0.96 W

Technical specifications

• Model name: HM96-HE-4
• Supply voltage: 24 VDC
• Power (per module): 0.96 W
• Luminous flux (per module): 144 lm
• Luminous efficacy: 150 lm/W
• Correlated Color Temperature (example model): 7000 K
• Color consistency: < 3 SDCM
• Lens: prismatic lens, 160° viewing angle for light diffusion
• Dimension: 90 x 15 mm
• Recommended installation thickness: 50 mm to 150 mm
• Fixing: 3M VHB adhesive with removal tab
• Protection rating: IP66/IP67
• Modules per chain: 40 pcs
• Modules per packaging: 80 pcs
