Hand pallet truck DFA series

for industrial applicationssteelfor warehouse

Product overview

• Manual hand pallet truck for moving and lifting pallets in warehouses and industrial environments.
• Available in four models with 2.5 t and 3.0 t rated capacities.
• Designed for easy entry with tapered fork tips; complies with EN1757-2.

Features

• Bushings at key points.
• Super strong steel structure frame.
• Tapered fork tips with entry guide roller.
• Fully adjustable push rods on forks.
• Conforms to EN1757-2.

Models and specifications
i-LIFT NO. | Model No. | Capacity kg(lb.) | Min. Fork Height mm(in.) | Max. Fork Height mm(in.) | Fork Length mm(in.) | Overall Forks Width mm(in.)
1112401 | DFA25S | 2500 (5500) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1150 (45.3) | 550 (21.7)
1112402 | DFA25L | 2500 (5500) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1220 (48) | 685 (27)
1112403 | DFA30S | 3000 (6600) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1150 (45.3) | 550 (21.7)
1112404 | DFA30L | 3000 (6600) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1220 (48) | 685 (27)

Technical specifications

• Series: DFA SERIES
• Available models: DFA25S, DFA25L, DFA30S, DFA30L
• Rated capacity: 2500 kg (5500 lb) and 3000 kg (6600 lb)
• Min. fork height: 85 or 75 mm (3.3 or 3 in)
• Max. fork height: 200 or 190 mm (7.9 or 7.5 in)
• Fork length: 1150 mm (45.3 in) or 1220 mm (48 in)
• Overall forks width: 550 mm (21.7 in) or 685 mm (27 in)
• Construction: Super strong steel structure frame with bushings at key points
• Fork tips: Tapered fork tips with entry guide roller
• Adjustability: Fully adjustable push rods on forks
• Standards: Conforms to EN1757-2
