Hydraulic pallet truck CA series

handfor industrial applicationsfor warehouse

Product Overview
Manual pallet truck series engineered for industrial material handling, offering controlled hydraulic descent and durable construction suitable for frequent use in warehouses and production facilities.

• Reliable hydraulic pump: German-made seal kits for the hydraulic pump ensure consistent performance and controlled lowering of the load.
• Bushings in key points: Reinforced bushings extend service life and simplify maintenance.
• Easy pallet entry and exit: Tapered fork tips and mounting brackets with entry rollers protect rollers and load wheels while facilitating fork entry/exit.
• Durable frame by heavy-duty design: Constructed from high-quality steel plate with continuous welds for enhanced structural integrity.
• Compliance: Conforms to EN1757-2.

Models / Technical Table
i-LIFT NO.; Model No.; Capacity kg(lb.); Min. Fork Height mm(in.); Max. Fork Height mm(in.); Fork Length mm(in.); Overall Forks Width mm(in.)
1110201; CA20S; 2000 (4400); 85 or 75 (3.3 or 3); 205 or 195 (8.1 or 7.7); 1150 (45.3); 530 (20.9)
1110202; CA20L; 2000 (4400); 85 or 75 (3.3 or 3); 205 or 195 (8.1 or 7.7); 1220 (48); 685 (27)
1110203; CA25S; 2500 (5500); 85 or 75 (3.3 or 3); 205 or 195 (8.1 or 7.7); 1150 (45.3); 530 (20.9)
1110204; CA25L; 2500 (5500); 85 or 75 (3.3 or 3); 205 or 195 (8.1 or 7.7); 1220 (48); 685 (27)

Notes
Special fork sizes available.

Technical specifications

• Series: CA series hand pallet truck
• Standards: Conforms to EN1757-2
• Hydraulic pump: German-made seal kits; controlled descending speed
• Bushings: Reinforced bushings at key points for extended life and easier repair
• Fork design: Tapered tip and mounting bracket with entry roller protection for smoother pallet handling
• Frame: Heavy-duty steel plate construction with continuous welds
• Available models and capacities: CA20S, CA20L (2000 kg / 4400 lb); CA25S, CA25L (2500 kg / 5500 lb)
• Fork lengths: 1150 mm (45.3 in) or 1220 mm (48 in)
• Overall forks width options: 530 mm (20.9 in) or 685 mm (27 in)
• Min fork height: 85 mm or 75 mm (3.3 or 3 in)
• Max fork height: 205 mm or 195 mm (8.1 or 7.7 in)
