Hydraulic pallet truck MP SERIES

handsteelgalvanised steel

Product overview

• The MP SERIES hand pallet truck is a manual pallet truck for horizontal transport and loading/unloading of palletised goods.
• Available capacities: 2000, 2500 and 3000 kg.

Key features

• Rubber-coated handle for comfortable grip in varying temperatures
• Fully sealed galvanized hydraulic unit with single valve cartridge for maintenance
• Powder-coated steel chassis
• Entry rollers to reduce pallet damage
• Conforms to EN1757-2

Models and specifications
i-LIFT NO. | Model No. | Capacity kg(lb.) | Min. Fork Height mm(in.) | Max. Fork Height mm(in.) | Fork Length mm(in.) | Overall Forks Width mm(in.)
1120101 | MP20S | 2000 (4400) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1150 (45.3) | 540 (21.3)
1120102 | MP20L | 2000 (4400) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1220 (48) | 685 (27)
1120103 | MP25S | 2500 (5500) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1150 (45.3) | 540 (21.3)
1120104 | MP25L | 2500 (5500) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1220 (48) | 685 (27)
1120105 | MP30S | 3000 (6600) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1150 (45.3) | 540 (21.3)
1120106 | MP30L | 3000 (6600) | 85 or 75 (3.3 or 3) | 200 or 190 (7.9 or 7.5) | 1220 (48) | 685 (27)

Technical specifications

• Fork lengths: 1150 mm (45.3 in) or 1220 mm (48 in)
• Overall forks width options: 540 mm (21.3 in) or 685 mm (27 in)
• Fork height range: Min 75 or 85 mm (3 or 3.3 in); Max 190 or 200 mm (7.5 or 7.9 in)
• Hydraulic unit: sealed galvanized housing; single valve cartridge for maintenance
• Handle: rubber-coated
• Compliance: EN1757-2

Options

• Special fork sizes available on request
