Electric stacker truck H series

battery-poweredwalk-behind48 V

Overview

• Handle-integrated battery display and operation controls for convenient handling.
• Drive unit equipped with electromagnetic brake.
• Complies with CE European safety standards.

HD-HM series

• Compact yet robust frame design suitable for narrow aisles.
• Lightweight, quick-change battery — replaceable in approximately 20 seconds to minimize downtime.
• 48V 15Ah lithium iron phosphate battery.

HQ-HM series

• Compact strong frame for restricted spaces.
• Large-capacity battery: 48V 30Ah lead-acid battery.

HK-HM series

• Reinforced steel structure for increased durability.
• Large-capacity battery: 48V 30Ah lead-acid battery.

Models and specifications
i-LIFT NO. | Model No. | Capacity kg(lb.) | Min. Fork Height mm(in.) | Max. Fork Height mm(in.) | Load Center mm(in.) | Wheelbase mm(in.)
1111406 | HK30-HM | 3000 (6600) | 80 (3.1) | 195 (7.7) | 475 (18.7)/510 (30) |
1111405 | HQ30-HM | 3000 (6600) | 80 (3.1) | 195 (7.7) | 475 (18.7)/510 (30) |
1111404 | HQ25-HM | 2500 (5500) | 80 (3.1) | 195 (7.7) | 475 (18.7)/510 (25) |
1111403 | HQ20-HM | 2000 (4400) | 80 (3.1) | 195 (7.7) | 475 (18.7)/510 (20) |
1111402 | HD20-HM | 2000 (4400) | 80 (3.1) | 195 (7.7) | 475 (18.7)/510 (20) |
1111401 | HD18-HM | 1800 (3960) | 75 (3) | 190 (7.5) | 600 (23.6) |

Technical features / specifications

• Series name: HHM SERIES
• Manufacturer / Brand: i-LIFT
• Safety: Complies with CE European safety standards
• Control: Handle-integrated battery display and operation controls
• Brake: Drive unit fitted with electromagnetic brake
• Battery types and capacities by sub-series: HD-HM = 48V 15Ah lithium iron phosphate; HQ-HM = 48V 30Ah lead-acid; HK-HM = 48V 30Ah lead-acid
• Battery feature (HD-HM): Lightweight, quick-replaceable battery (approx. 20 seconds)
• Frame: HD/HQ = compact strong frame for narrow aisles; HK = reinforced steel structure for enhanced durability
• Model capacities (kg / lb): 1800 (3960), 2000 (4400), 2500 (5500), 3000 (6600)
• Min. fork height (mm/in.): 75 (3) for HD18-HM; 80 (3.1) for other listed models
• Max. fork height (mm/in.): 190 (7.5) for HD18-HM; 195 (7.7) for other listed models
• Load center options (mm/in.): examples include 475 (18.7) and 510 (20/25/30) depending on model; HD18-HM listed as 600 (23.6)
• Models included: HD18-HM (1111401), HD20-HM (1111402), HQ20-HM (1111403), HQ25-HM (1111404), HQ30-HM (1111405), HK30-HM (1111406)
