Diaphragm compressor DAA-P501-EB
airACstationary

Diaphragm compressor - DAA-P501-EB - JUN-AIR - air / AC / stationary
Diaphragm compressor - DAA-P501-EB - JUN-AIR - air / AC / stationary
Add to favorites
Compare this product

Characteristics

Technology
diaphragm
Type
air
Power source
AC
Portability
stationary
Lubrication
oil-free
Applications
for medical devices
Voltage
115 V
Other characteristics
compact, low-noise, energy-saving, electric
Pressure

4.14 bar
(60.05 psi)

Flow

Max.: 4.08 m³/h
(144.08 ft³/h)

Min.: 0.51 m³/h
(18.01 ft³/h)

Power

0.19 kW
(0.26 hp)

Length

298.7 mm
(11.76 in)

Width

145.5 mm
(5.73 in)

Height

194.8 mm
(7.67 in)

Weight

13 kg
(28.7 lb)

Noise level

70 dB

Description

Description The DAA-P501-EB diaphragm compressor is a compact model from the Diaphragm series designed for accurate, low-noise operation. It functions as both a compressor and a vacuum pump, tolerates the presence of liquids and can operate at low temperatures. Engineered for tight sealing, it delivers reliable pressure and clean, contaminant-free air. The DAA-P501-EB unit shown is 1/4 HP, operates at 115 VAC (60 Hz) with a maximum continuous pressure of 60 PSI and an open flow of approximately 2.4 CFM (60 Hz).

Key features
  • Chemically resistant materials: PPS components and EPDM seals for chemical, heat and corrosion resistance.
  • EMI suppression: protection for sensitive electronic components.
  • Versatile functionality: operates as compressor and vacuum pump; available in bi-frequency, PSC and multivoltage versions.
  • Reliability: durable materials and components to reduce downtime and maintenance.

Applications
  • Medical sector and medical devices
  • Food and beverage industry
  • Environmental monitoring, sampling and precise measurements
  • Low-noise and low-power consumption applications

Versions and delivered accessories Supplied in standard version with muffler for vacuum applications and motor capacitor. The DOA/DAA series offers optional laboratory versions (vacuum and pressure gauges, fittings, regulators, handle, rubber feet) and variants with PTFE membrane head/cover, neoprene membrane and stainless steel valves.

Technical characteristics / specifications
  • Reference: DAA-P501-EB
  • Series: Diaphragm
  • Description: Diaphragm compressors
  • HP: 0.25 (1/4 HP)
  • Voltage (50 Hz / 60 Hz / DC): 110 V (50 Hz) / 115 V (60 Hz) / - (DC not applicable)
  • Amps (50 Hz / 60 Hz / DC): 2.8 A (50 Hz) / 2.7 A (60 Hz) / -
  • Open flow (50 Hz / 60 Hz): 1.9 CFM (54 LPM) at 50 Hz / 2.4 CFM (68 LPM) at 60 Hz
  • Maximum pressure: 60 PSI (4.14 bar)
  • Flow at maximum pressure (50 Hz / 60 Hz): 0.2 CFM (5.7 LPM) at 50 Hz / 0.3 CFM (8.5 LPM) at 60 Hz
  • Weight: 28 lb / 13 kg
  • Noise level: 70 dBA
  • Phase: Single-phase
  • Regulatory compliance: CE
  • Dimensions (in/us): 11.76 L x 5.73 W x 7.67 H
  • Dimensions (metric): 298.7 L x 145.5 W x 194.8 H mm
  • Mounting dimensions (in/us): 10 L x 3.5 W
  • Mounting dimensions (metric): 254.0 L x 88.9 W mm
  • Country of origin: United States
