Piston compressor 1HAB-10-M100X

airelectrically-poweredstationary

Description
The 1HAB-10-M100X is an oil-free single-cylinder tank-mounted piston compressor engineered to deliver clean, contaminant-free compressed air. Rated at 1/6 HP and operating at 115 V AC, it provides a maximum continuous pressure of 100 PSI and an open-flow of 1.3 CFM (37 LPM).

Design and range
Models 1L-1H-1V and 2L-2H are compact tank-mounted single-cylinder units covering a broad range of pressures and flow rates. Their oil-free design and corrosion-resistant internal components support reliable operation and maintain air purity across demanding industrial environments.

Applications
These units are suitable for continuous high-pressure tasks such as cable pressurization, inflation, high-pressure spraying and general industrial processes. Model 2V variants provide reliable vacuum for component testing, material handling and food preservation processes important in automotive, manufacturing and food & beverage sectors.

Key features

• Oil-free operation: Delivers clean air free of oil contaminants
• High-pressure capability: Suitable for applications requiring sustained elevated pressure
• Tank-mounted: Available with tanks from 2 to 60 gallons

Product information (summary)

• Reference / SKU: 1HAB-10-M100X
• Series: Piston
• Type: Piston compressors
• Country of origin: UNITED STATES
• Design: Oil-free

Technical specifications

• HP: 0.17 (1/6 HP)
• Amps (60 Hz): 3.5 A
• Weight: 17 lb (8 kg)
• Open flow (60 Hz): 1.3 CFM (37 LPM)
• Flow at max pressure (60 Hz): 0.4 CFM (11.3 LPM)
• Voltage (60 Hz): 115 V AC
• Maximum pressure: 100 PSI (6.89 bar)
• Phase: Single-phase
• Regulatory: cURus
• Sound level: 70 dBA
• Dimensions (L x W x H): 11.53 x 5.63 x 8.46 in (292.9 x 143.0 x 214.9 mm)
• Mounting dimensions: 2.75 x 4.25 in (69.9 x 108.0 mm)
