Piston compressor 7HDD-10-M750X
airACstationary

Piston compressor - 7HDD-10-M750X - JUN-AIR - air / AC / stationary
Piston compressor - 7HDD-10-M750X - JUN-AIR - air / AC / stationary
Add to favorites
Compare this product

Characteristics

Technology
piston
Type
air
Power source
AC
Portability
stationary
Lubrication
oil-free
Application domain
industrial, for food applications
Voltage
230 V, 115 V
Other characteristics
tank-mounted, with tank, high-pressure, high-performance
Tank volume

Max.: 227.1 l
(60 gal)

Min.: 7.6 l
(2 gal)

Pressure

6.89 bar
(99.93 psi)

Flow

Max.: 15.29 m³/h
(539.96 ft³/h)

Min.: 8.49 m³/h
(299.82 ft³/h)

Power

1.12 kW
(1.52 hp)

Length

533.4 mm
(21 in)

Width

304.3 mm
(11.98 in)

Height

213.4 mm
(8.4 in)

Weight

32 kg
(70.5 lb)

Noise level

76 dB

Description

Overview
The 4-cylinder tank-mounted compressor (7HDD-10-M750X) provides long service life for a wide range of industrial applications. Oil-free piston design delivers clean compressed air free of contaminants. The 1.5 HP model operates at 115/208-230 V AC, with a maximum continuous pressure of 100 PSI and a free air delivery of 9 CFM.

Detailed description
Part of the 7H and 8H series, these 4-cylinder tank-mounted piston compressors are designed for demanding applications and harsh operating conditions. Mid-to-compact size piston compressors deliver compressed air across a broad range of pressures and flow rates. Internal components are corrosion-resistant and the oil-free design ensures reliable operation with contaminant-free air.

Typical applications
  • Cable pressurization
  • Inflation
  • Spray painting
  • General industrial applications, food and beverage, automotive and manufacturing

Key features
  • Oil-free operation: Provides clean, contaminant-free air
  • High-pressure capability: Suited for sustained high-pressure applications
  • Tank-mounted: Tanks available from 2 to 60 gallons

Available documents
Datasheets, user manual and product brochures available for download (see Downloads section).

Technical specifications
  • Reference: 7HDD-10-M750X
  • Series: Piston
  • Type: Tank-mounted piston compressor, 4 cylinders
  • Design: Oil-free, corrosion-resistant internal components
  • Power (HP): 1.5 HP
  • Voltage (60 Hz): 115/208-230 V AC
  • Amperage (60 Hz): 20/10
  • Free air delivery (60 Hz): 9 CFM (255 LPM)
  • Flow at max pressure (60 Hz): 5 CFM (141.6 LPM)
  • Maximum continuous pressure: 100 PSI (6.89 bar)
  • Weight: 70 lb (32 kg)
  • Sound level: 76 dBA
  • Dimensions (standard): 21 L x 11.98 W x 8.4 H (inches)
  • Dimensions (metric): 533.4 L x 304.3 W x 213.4 H (mm)
  • Mounting dimensions (standard): 3 L x 4.88 W (inches)
  • Mounting dimensions (metric): 76.2 L x 124.0 W (mm)
  • Regulatory: CSA certified
  • Country of origin: United States
  • Tank options: 2 to 60 gallons available
