Fiber laser cutting machine ACE Laser 4020 6.0 R

for metalsheet metalCNC

Overview
The ACE Laser series provides a fiber laser cutting system designed for industrial cutting tasks with reproducible part quality. Configurations cover small lot one-offs up to high-volume series production. Standard equipment supports safety, productivity and ease of integration in manufacturing lines.

Highlights

• Gantry design with double-sided drives
• Complete cutting package including filter extraction
• KNUTH service: installation, commissioning and maintenance

Product Details

• Gantry-style construction with drives on both sides and working areas from 3,000 x 1,500 mm up to 6,000 x 2,000 mm
• Y-axis portal in die-cast aluminum for low weight and high rigidity, improving dynamics
• Welded, thermally relieved machine frame to remove production stresses and ensure long-term alignment
• Precision linear guides designed for low maintenance and high cutting speeds
• High-precision rack-and-pinion gears on the Y and Z axes for reliable positioning
• Servo motors on all axes for consistent motion performance
• Enclosed machine housing with protective glass windows for operator safety and process observation
• Automatic shuttle table allows loading/unloading during cutting to reduce downtime
• Perpendicularity / squareness tolerance for laser cutting according to DIN EN ISO 9013-1

Control

• User-friendly interface and optimized operation for quick setup
• Technology database with cutting parameters and preset cycles for various metals
• Software support for nesting and process parameter selection to optimize job processing
• Solenoid and proportional valves controlled via CNC to regulate gas pressures during cutting

Cutting head

• RayTools cutting head with motorized focus adjustment, integrated collision protection and height control
• Maintenance-free beam guidance via flexible fiber optic cable
• For systems from 6 kW, BOCI high-performance cutting head available for high-power cutting

Laser sources

• Ytterbium fiber laser (Raycus) available between 1,000 and 6,000 W; maintenance-free design
• Low operating and maintenance costs due to fiber laser technology
• Higher power configurations available on request

Technical specifications

• Working area
  Table dimensions: 4.000 mm x 2.000 mm
  Workpiece weight (max.): 1.500 kg
  Axis acceleration X/Y: 10 m/s²
  Axis acceleration Z: 5 m/s²
• Travels
  Travel X-axis: 2.020 mm
  Travel Y-axis: 4.050 mm
  Travel Z-axis: 100 mm
• Rapid feed
  Rapid feed: 100 m/min
  Change time at cutting table: 12 s - 17 s
• Accuracies
  Positioning accuracy: 0.03 mm/m
  Repeatability: 0.02 mm/m
• Laser
  Fiber laser: 6.000 W
  Wavelength: 1.08 ± 10% µm
  Beam power max.: 6.000 W
  Pulse frequency: 50 ~ 20k Hz
  Power consumption: 20 kW
  Supply voltage: AC 380V ± 10%, 50/60Hz, 3xL+N
  Cutting capacity (structural steel): 22 mm
  Cutting capacity (stainless steel): 14 mm
  Cutting capacity (aluminum): 12 mm
• Drive capacity
  Machine drive X-axis: 1 kW
  Machine drive Y-axis: 1.5 kW
  Machine drive Z-axis: 0.4 kW
• Dimensions and weight
  Overall dimensions (L x W x H): 10.34 m x 4.28 m x 2.2 m
  Weight: 9.000 kg
