Fiber laser cutting machine ACE Laser 6020 1.5 R

for metalsheet metalCNC

Overview
The ACE Laser 6020 1.5 R is a gantry-style fiber laser cutting machine designed for industrial plate processing. It covers working areas up to 6,000 x 2,000 mm and delivers a nominal beam power of 1,500 W, suitable for single-part production and series manufacturing in electronics, aerospace and automotive supply chains.

Highlights

• Gantry (bridge) construction with bilateral drives for stable dynamics
• Complete cutting package including enclosure and dust extraction
• Automatic shuttle table to minimize loading/unloading downtimes

Working area
Table dimensions: 6,000 mm x 2,000 mm
Maximum workpiece weight: 2,000 kg
Axis acceleration X / Y: 8 m/s² — Z: 5 m/s²

Travels
Travel X-axis: 2,020 mm
Travel Y-axis: 6,050 mm
Travel Z-axis: 120 mm

Rapid feed
Rapid traverse: 80 m/min
Table change time: 15 s – 20 s

Accuracies
Positioning accuracy: 0.05 mm/m
Repeatability: 0.03 mm/m

Laser
Fiber laser (Yb): 1,500 W nominal beam power
Wavelength: 1.08 ± 10% µm
Power consumption: 5.3 kW
Supply voltage: AC 380 V ± 10%, 50/60 Hz, 3xL+N
Typical cutting capacities: structural steel 12 mm, stainless steel 4 mm, aluminum 3 mm

Drive capacity
Drive power X-axis: 2 kW
Drive power Y-axis: 2 kW
Drive power Z-axis: 0.4 kW

Measures and weights
Overall dimensions (L x W x H): 16.3 m x 4.74 m x 2.15 m
Machine weight: 17,800 kg

Product Details

• Gantry construction with drives on both sides and large table variants to fit common plate formats
• Y-axis portal in aluminum die-cast for low weight and high rigidity, improving dynamics
• Welded frame with thermal stress relief to ensure long-term geometric stability
• Precision linear guides and high-precision rack-and-pinion transmissions on Y/Z axes for durable accuracy
• Servo drives on all axes for consistent positioning performance
• Enclosure with safety glass windows and filter extraction for operator protection and environmental compliance
• Automatic shuttle table enables loading/unloading during cutting to increase throughput
• Perpendicularity and squareness tolerances for laser cutting per DIN EN ISO 9013-1

Control

• User-friendly CNC interface with large display
• Technology database with preset cutting parameters for common metals
• CypCut/CypNest compatible for nesting and CAD/CAM workflow (supports Ai, DXF, PLT, LXD)
• Solenoid and proportional valves controlled from CNC for gas pressure regulation

Cutting head

• RayTools cutting head with motorized focus adjustment, collision protection and height control
• Maintenance-free beam guidance via flexible fiber optic cable
• High-power configurations (from ~6 kW) use specialized cutting heads (e.g., BOCI)

Laser Sources

• Ytterbium fiber laser options (Raycus) from 1,000 to 6,000 W available on request
• Maintenance-reduced laser source lowers operating costs
• Higher power variants available for increased cutting capacity

Technical specifications

• Table dimensions: 6,000 mm x 2,000 mm
• Maximum workpiece weight: 2,000 kg
• Travel X / Y / Z: 2,020 mm / 6,050 mm / 120 mm
• Rapid traverse: 80 m/min
• Table change time: 15 s – 20 s
• Positioning accuracy: 0.05 mm/m — Repeatability: 0.03 mm/m
• Fiber laser power (this configuration): 1,500 W
• Wavelength: 1.08 ± 10% µm
• Power consumption: 5.3 kW — Supply voltage: AC 380 V ± 10%, 50/60 Hz, 3xL+N
• Cutting capacities (examples): structural steel 12 mm, stainless steel 4 mm, aluminum 3 mm
• Drive capacities X / Y / Z: 2 kW / 2 kW / 0.4 kW
• Overall dimensions: 16.3 m x 4.74 m x 2.15 m — Weight: 17,800 kg
