Fiber laser cutting machine ACE Laser 6020 3.0 R

for metalsheet metalCNC

Overview
The ACE Laser series is a fiber laser cutting system engineered for industrial plate processing, offering precise part quality, high productivity and robust automation. Complete standard equipment and automated shuttle table options enable efficient workflows from single-piece production to large serial runs in electronics, aerospace and automotive sectors.

Highlights

• Gantry-style construction with dual-side drives and large working area
• Automatic shuttle table system for loading/unloading during cutting to minimise downtime
• Complete extraction and filtration package; machine enclosure with safety glazing for process observation

Product details

• Aluminium die-cast Y-axis portal for low weight, high stiffness and excellent dynamics
• Thermally treated welded machine frame to remove manufacturing stresses and ensure long-term geometric stability
• Precision linear guides and high-precision rack-and-pinion drives on Y/Z for reliable positioning at high cutting speeds
• Powerful servo motors on all axes and maintenance-free fiber beam delivery
• Automatic shuttle table reduces production downtime by enabling part exchange during cutting
• Perpendicularity / squareness tolerance for laser cutting according to DIN EN ISO 9013-1

Control & software

• User-friendly CNC control with large display and technology database containing pre-set cutting parameters
• CAD/CAM support (CypCut/CypNest): material library, nesting, support of Ai/DXF/PLT/LXD formats and real-time power adjustment
• Ethernet access for diagnostics and optional integrated camera monitoring
• Gas control via solenoid and proportional valves (configurable in control)

Cutting head

• RayTools cutting head with motorised focus adjustment, integrated collision protection and height control
• Maintenance-free beam guide via flexible fibre optic cable
• BOCI cutting-head option available for higher-power systems (from ≈6 kW)

Laser sources

• Ytterbium fiber lasers (Raycus) available from 1.000 W to 6.000 W; standard shown: 3.000 W
• Long-life, low-maintenance laser source to reduce operating costs; higher powers available on request

Technical specifications

• Model: ACE Laser 6020 3.0 R
• Working area — Table dimensions: 6.000 mm x 2.000 mm; Max. workpiece weight: 2.000 kg
• Travels — X: 2.020 mm; Y: 6.050 mm; Z: 120 mm
• Rapid feed: 80 m/min; Shuttle change time: 15 s - 20 s
• Positioning accuracy: 0,05 mm/m; Repeatability: 0,03 mm/m
• Laser — Fiber laser: 3.000 W; Wavelength: 1,08 ± 10% µm; Power consumption: 12 kW; Supply voltage: AC 380V ± 10%, 50/60Hz, 3xL+N
• Cutting capacity — Structural steel: 18 mm; Stainless steel: 6 mm; Aluminum: 5 mm
• Drive power — X-axis: 2 kW; Y-axis: 2 kW; Z-axis: 0,4 kW
• Machine dimensions (L x W x H): 16,3 m x 4,74 m x 2,15 m; Weight: 17.800 kg
