Fiber laser cutting machine ACE PRO 6025 20R

for metalsheet metalCNC

Product overview
The ACE Laser PRO 6025 20R is an industrial fiber laser cutting machine engineered for sheet and plate processing up to 6,000 × 2,500 mm. It is configured here with a 20 kW fiber laser and a shuttle table system for continuous loading/unloading to minimize downtime.

Highlights

• Laser power options from 12 to 30 kW (configurations up to 40 kW available)
• Welded, stress-relieved frame and industrial-grade components for dimensional stability
• Complete cutting package with filtered vacuum extraction
• KNUTH service: installation, commissioning and maintenance support

Working area
Table dimensions: 6,000 × 2,500 mm
Max. workpiece weight: 5,000 kg
Axis acceleration X / Y: 15 m/s² — Z: 15 m/s²

Travels
Travel X: 6,350 mm
Travel Y: 2,550 mm
Travel Z: 370 mm

Rapid feed
Rapid feed X / Y: 180 m/min
Rapid feed Z: 35 m/min
Table change time: 23–25 s

Accuracies
Positioning accuracy: 0.03 mm/m
Repeatability: 0.03 mm/m

Laser
Fiber laser power: 20,000 W (CW)
Wavelength: 1.08 ± 0.5% µm
Supply voltage: AC 380 V ± 10%
Typical cutting capacities: structural steel 40 mm — stainless steel 30 mm — aluminum 25 mm

Drive capacity
X-axis drive: 2.9 kW
Y-axis drive: 1.3 kW
Z-axis drive: 0.75 kW

Dimensions and weight
Overall (L × W × H): 16.12 m × 4.55 m × 2.61 m
Weight: 13,500 kg

Control

• FSCUT8000 CNC with EtherCAT bus tailored for high-power fiber lasers (>8 kW)
• User-oriented interface with advanced nesting and production functions
• HypCut software for production planning and scheduling

Cutting head

• BLT 6 series smart cutting heads for high-power cutting (compatible up to 40 kW)
• Optimized beam path, protective optics design and dual dust extraction for reliable operation and straightforward maintenance
• Smart-Piercing and Auto-Recut functions with real-time sensors to detect and correct uncut sections
• Drawer-type optics access for rapid replacement of lens guards and lenses

Height control

• Capacitive height sensing with Ethernet communication: height detection, segmented plunge, edge detection and vibration suppression
• Anti-collision function to prevent tilt collisions during production

Laser source

• HP series CW multi-module fiber lasers (e.g., Raycus) available from 4 kW up to 40 kW
• High electro-optical conversion efficiency and wide modulation bandwidth reduce operating cost
• Maintenance-free design lowers service requirements

Standard equipment and system features

• Complete system with FSCUT8000 CNC
• HypeCut CAD/CAM and nesting support
• Automatic changer shuttle table for reduced downtime
• Central lubrication, cooling unit, proportional valve (Aventics), extraction and filtration unit
• Laser safety cabin and filtered vacuum extraction
• Operating manual and documentation

Technical specifications

• Model: ACE Laser PRO 6025 20R
• Working area (table): 6,000 × 2,500 mm
• Max. workpiece weight: 5,000 kg
• Travel X / Y / Z: 6,350 / 2,550 / 370 mm
• Rapid feed X/Y: 180 m/min — Z: 35 m/min
• Positioning accuracy / Repeatability: 0.03 mm/m
• Laser type & power: Fiber laser — 20,000 W
• Supply voltage: AC 380 V ± 10%
• Cutting capacities (approx.): structural steel 40 mm — stainless steel 30 mm — aluminum 25 mm
• Overall dimensions (L × W × H): 16.12 m × 4.55 m × 2.61 m
• Weight: 13,500 kg
