Fiber laser cutting machine ACE Laser 6020 6.0 R

for metalsheet metalCNC

Product description
The ACE Laser 6020 6.0 R is a fiber laser cutting machine intended for industrial sheet-metal production. It combines a gantry-style cutting platform, an automatic shuttle table and a fiber laser source to support single-piece processing and series production with predictable process parameters and repeatable results.

Highlights

• Gantry-style construction with bilateral drive for large-format plates
• Automatic shuttle table for loading/unloading during cutting to reduce cycle time
• Complete CNC package with remote access and visualization

Product details

• Working area: 6,000 x 2,000 mm (table)
• Maximum workpiece weight on table: 2,000 kg
• Gantry Y-axis in aluminum die-cast for reduced mass and enhanced rigidity
• Welded machine frame with thermal stress relief to secure long-term alignment
• Precision linear guides and rack-and-pinion drives for accurate high-speed motion
• Servo motors on all axes; axis accelerations: X/Y = 8 m/s², Z = 5 m/s²
• Protected machine enclosure with special glass windows and interlocked front doors

Control & Software

• CNC control (FSCUT2000) with user-optimised interface and remote access via Ethernet
• Technology database with predefined cutting parameters and cycles for common metals
• Built-in CypCut nesting and cutting software; CypNest offline nesting available
• Gas control via solenoid and proportional valves managed from the CNC

Cutting head

• RayTools cutting head with motorized autofocus, collision protection and height control
• Fiber beam delivery via flexible fiber cable; maintenance-free beam path
• Option: BOCI high-pressure cutting head for configurations ≥ 6 kW

Laser sources

• Ytterbium fiber laser (e.g., Raycus) available from 1,000 W to 6,000 W; standard configuration 6,000 W
• Maintenance-free laser source to reduce operating costs
• Higher power options available on request

Standard equipment (selection)

• Complete CNC system (FSCUT2000) and CypCut software
• Automatic shuttle (exchange) table
• Extraction and filtration unit (e.g. 4,000 m³ modules)
• Gas console with automatic electro-valves for O2 and N2
• Recirculating water chiller for laser source
• Central lubrication system and operating manual

Optional equipment (selection)

• Refrigerated compressed air dryer (dew point +3 °C) with filters
• Oxygen pressure reducer (200 or 300 bar → 0–20 bar)
• Nitrogen pressure reducer (200 or 300 bar → 0–50 bar)

Technical specifications

• Model: ACE Laser 6020 6.0 R
• Working area (table): 6,000 x 2,000 mm
• Max. workpiece weight: 2,000 kg
• Axis travels (X / Y / Z): 2,020 mm / 6,050 mm / 120 mm
• Rapid feed: 80 m/min; shuttle table change time: 15–20 s
• Positioning accuracy: 0.05 mm/m; repeatability: 0.03 mm/m
• Laser: fiber Yb, standard 6,000 W; wavelength ~1.08 µm
• Electrical power consumption: 20 kW; supply: AC 380V ±10%, 50/60 Hz, 3xL+N
• Typical cutting capacities: structural steel 20 mm; stainless steel 12 mm; aluminium 12 mm
• Machine dimensions (L x W x H): 16.3 m x 4.74 m x 2.15 m; weight: 17,800 kg
