Fiber laser cutting machine ACE Laser PRO 6025 12R

for metalsheet metalCNC

Overview
ACE Laser PRO 6025 12R is an industrial fiber laser cutting system designed for high-power cutting tasks and heavy workpieces. It delivers repeatable precision, efficient material handling and integrated safety features for series production and single-piece complex parts in sectors such as automotive, aerospace and electronics.

Highlights

• Standard configuration with 12 kW fiber laser (options up to 30–40 kW)
• Large-format working area: up to 6000 x 2500 mm
• Automatic changer table for simultaneous loading/unloading
• Complete cutting package with filtered vacuum extraction and safety enclosure

Product details

• Machine construction: thermally treated welded frame for stress-free, long-term geometric stability
• Precision linear guides and high-precision rack-and-pinion drives on X/Y for reliable positioning
• High-dynamic servo drives on all axes for fast acceleration and responsive control
• Enclosed cutting area with safety viewing window for operator protection
• Table change system minimizes downtime by enabling loading/unloading during cutting
• Designed for heavy parts — max workpiece weight up to 5,000 kg (model dependent)

Control

• FSCUT8000 CNC based on EtherCAT for high-power laser applications
• User-friendly HMI with production-focused functions
• HypCut software for production planning, nesting and scheduling of high-power cutting jobs

Cutting head

• BLT 6 series smart cutting heads optimized for high-power fiber lasers (up to 40 kW)
• Optimized beam path, dual dust protection and quick-change drawer design for fast maintenance
• Smart-Piercing and Auto-Recut functions with real-time sensors to improve yield and reduce rework
• Lens guard monitoring and easy replacement of optical elements

Height control & protection

• Capacitive height sensing integrated in FSCUT for edge detection, segmented plunging and vibration suppression
• Anti-collision features to prevent tilt collisions during automatic operations

Laser source

• Multi-module CW fiber lasers (Raycus HP series) with high electro-optical efficiency and wide modulation bandwidth
• Maintenance-free design to reduce operating costs

Standard equipment & main accessories

• FSCUT8000 CNC control
• HypCut CAD/CAM (option: CypNest offline nesting)
• Ytterbium fiber laser (Raycus)
• BOCI BLT 6 autofocus cutting head
• Filtered extraction unit (e.g. 6000 m³/h)
• Laser safety enclosure and automatic changer table system

Optional equipment

• High-pressure oxygen regulators (200 bar / 0–20 bar or 300 bar / 0–20 bar)
• Pneumatic dryer for compressed air (dew point +3°C, service pressure 16 bar)

Technical specifications

• Model: ACE Laser PRO 6025 12R
• Working area (table): 6,000 x 2,500 mm
• Max workpiece weight: 5,000 kg
• Travel (X / Y / Z): 6,350 / 2,550 / 370 mm
• Acceleration X/Y/Z: 15 m/s² / 15 m/s²
• Rapid feed X/Y: 180 m/min; Z: 35 m/min
• Table change time: 23–25 s
• Positioning accuracy / Repeatability: 0.03 mm/m
• Fiber laser (standard): 12,000 W (options available)
• Wavelength: 1.08 ± 0.5% µm
• Supply voltage: AC 380V ± 10%
• Cutting capacity (approx.): structural steel 30 mm; stainless steel 25 mm; aluminium 18 mm
• Drive power X / Y / Z: 2.9 kW / 1.3 kW / 0.75 kW
• Overall dimensions (L x W x H): 16.12 m x 4.55 m x 2.61 m
• Weight: 13,500 kg
