Stainless steel pipe elbow 90CR series

90°

Product overview

Curved 90° reducing elbow equipped with KF flanges to connect components with different nominal diameters (DN). Available in multiple DN configurations, designed for vacuum connection applications in industrial and laboratory systems.

Variants / Items:

• 90CR2516KF-4
  • Material: AISI 304
  • Finish: microblasted
  • DN: 25/16
  • A: 40 mm (1.575 inch)
  • B: 30 mm (1.181 inch)
  • C: 36 mm (1.417 inch)
  • D: 40 mm (1.575 inch)
  • E: -
  • F: -
• 90CR4025KF-4
  • Material: AISI 304
  • Finish: microblasted
  • DN: 40/25
  • A: 55 mm (2.165 inch)
  • B: 40 mm (1.575 inch)
  • C: 42 mm (1.654 inch)
  • D: 50 mm (1.969 inch)
  • E: -
  • F: -
• 90CR5040KF-4
  • Material: AISI 304
  • Finish: microblasted
  • DN: 50/40
  • A: 75 mm (2.953 inch)
  • B: 55 mm (2.165 inch)
  • C: 60 mm (2.362 inch)
  • D: 65 mm (2.559 inch)
  • E: -
  • F: -

Features / Technical specifications:

• Line standard: KF
• Line type: KF
• Product type: Connection fittings
• Angle: 90°
• Material available as indicated: AISI 304 (see item table)
• Finish: microblasted (see item table)
• Documentation available: commercial datasheet, technical datasheet (see PDF files in documents section)

Applications

• Vacuum piping and connection systems
• Laboratory and research vacuum setups
• Industrial vacuum lines and pump connections
• Systems requiring transition between different DN KF components

Documentation & ordering

• Product datasheet and technical sheet available as PDF
• Specify model code and DN when ordering
• Contact sales for lead times and custom configurations
