Flange connector union 4C series

Straight connector equipped with CF flanges, designed for in-line vacuum connections. Available in AISI 304 with mechanically polished exterior and raw interior.

Available variants (items):

• D16CF-76-4 — Material: AISI 304; Finish: mechanically polished exterior and raw interior; DN: 16; A: 34 mm (1.339 in); B: 27 mm (1.063 in); C: 76 mm (2.992 in)
• D38CF-126-4 — Material: AISI 304; Finish: mechanically polished exterior and raw interior; DN: 38; A: 70 mm (2.756 in); B: 58.7 mm (2.311 in); C: 126 mm (4.961 in)
• D63CF-210-4 — Material: AISI 304; Finish: mechanically polished exterior and raw interior; DN: 63; A: 113 mm (4.449 in); B: 92.2 mm (3.63 in); C: 210 mm (8.268 in)
• D100CF-270-4 — Material: AISI 304; Finish: mechanically polished exterior and raw interior; DN: 100; A: 152 mm (5.984 in); B: 130.3 mm (5.13 in); C: 270 mm (10.63 in)
• D150CF-334-4 — Material: AISI 304; Finish: mechanically polished exterior and raw interior; DN: 150; A: 202 mm (7.953 in); B: 181 mm (7.126 in); C: 334 mm (13.15 in)
• D200CF-406-4 — Material: AISI 304; Finish: mechanically polished exterior and raw interior; DN: 200; A: 253 mm (9.961 in); B: 231.8 mm (9.126 in); C: 334 mm (13.15 in)
• D250CF-456-4 — Material: AISI 304; Finish: mechanically polished exterior and raw interior; DN: 250; A: 306 mm (12.047 in); B: 284 mm (11.181 in); C: 420 mm (16.535 in)

Features / technical specifications:

• Line: CF
• Line type: CF
• Product type: connection fittings (straight connector with CF flanges)
• Material available: AISI 304
• Finish: mechanically polished exterior, raw interior
• Technical documentation available: commercial product sheet and technical data sheet (PDF)
• Technical image available (dimensional drawing)
