Anchoring system JIS Stock

Product Overview
JIS stock anchor is a traditional fixed-stock anchor designed to JIS requirements for anchoring fishing vessels, workboats, barges and permanent mooring systems. Constructed from marine-grade cast steel with a forged or cast shank, fixed transverse stock, crown and two flukes, the design ensures one fluke penetrates the seabed rapidly to develop holding power. Standard nominal weights range from 500 to 20,000 kg; larger sizes available on request. Certification from major classification societies can be provided.

Introduction
The JIS stock anchor features a fixed transverse stock placed perpendicular to the shank. On deployment the stock forces one fluke into the bottom while the other remains exposed, delivering stable seating and reliable holding on soft to medium seabeds (mud, sand, clay and mixed bottoms). The fixed stock prevents rolling after landing, improving holding performance for long-term moorings and work platforms.

Product Features

• Traditional fixed-stock anchor geometry
• Fixed transverse stock for stable landing
• Marine-grade cast steel construction with heat treatment and machining
• Nominal weight range: 500–20,000 kg (standard); larger sizes on request
• Suitable for mud, sand, clay and mixed seabeds
• Stable holding after penetration; compatible with stud link anchor chain systems
• Permanent identification marking and full traceability

Parameter
Nominal Weight(kg) | L | L1 | L2 | H | H1 | B
100 | 540 | 378 | 750 | 91 | 395 | 230
125 | 580 | 405 | 810 | 97 | 425 | 248
150 | 612 | 432 | 855 | 104 | 452 | 264
180 | 650 | 459 | 910 | 111 | 480 | 280
240 | 720 | 510 | 1010 | 122 | 530 | 310
280 | 760 | 534 | 1060 | 130 | 560 | 325
300 | 770 | 540 | 1080 | 131 | 570 | 331
320 | 790 | 560 | 1100 | 132 | 580 | 338
360 | 820 | 580 | 1150 | 139 | 610 | 353
420 | 860 | 610 | 1200 | 146 | 640 | 370
480 | 900 | 640 | 1260 | 153 | 670 | 387
570 | 950 | 670 | 1330 | 162 | 700 | 408
660 | 660 | 710 | 1440 | 170 | 740 | 430
780 | 1060 | 750 | 1480 | 180 | 780 | 456
900 | 1110 | 780 | 1550 | 189 | 820 | 477
1020 | 1160 | 820 | 1620 | 197 | 860 | 500
1140 | 1200 | 850 | 1680 | 204 | 890 | 520
1290 | 1250 | 880 | 1750 | 212 | 920 | 540
1440 | 1300 | 920 | 1820 | 221 | 960 | 560
1590 | 1340 | 950 | 1880 | 228 | 990 | 580
1740 | 1380 | 980 | 1930 | 235 | 1020 | 600
1920 | 1430 | 1010 | 2000 | 243 | 1060 | 620
2100 | 1470 | 1040 | 2060 | 250 | 1090 | 640
2280 | 1510 | 1070 | 2110 | 257 | 1120 | 650
2460 | 1550 | 1100 | 2170 | 264 | 1150 | 670
2640 | 1590 | 1120 | 2230 | 270 | 1180 | 690
2850 | 1630 | 1150 | 2280 | 277 | 1210 | 700
3060 | 1670 | 1180 | 2340 | 284 | 1214 | 720
3780 | 1790 | 1260 | 2510 | 304 | 1320 | 770
4890 | 1950 | 1380 | 2730 | 332 | 1440 | 840
5610 | 2040 | 1440 | 2860 | 347 | 1510 | 880
8700 | 2380 | 1670 | 3320 | 403 | 1750 | 1020
15400 | 2860 | 2020 | 4000 | 486 | 2110 | 1230
29000 | 3530 | 2490 | 4840 | 600 | 2610 | 1520
38500 | 3880 | 2740 | 5430 | 660 | 2860 | 1670
46000 | 4120 | 2910 | 5770 | 700 | 3040 | 1770

Standards
Name: JIS Stock Anchor
MOQ: 1 Piece
Package: Steel pallet / Wooden crate / Bulk packing
Manufacturing standards: Produced from marine-grade cast steel in accordance with Japanese Industrial Standards (JIS) and applicable marine anchor manufacturing specifications. Production follows IACS UR A1, ISO 1704 and classification society requirements. Certificates from ABS, BV, CCS, DNV, LR, NK, KR, RINA, RS and RMRS available upon request.

Testing and Maintenance
Testing standards: Each anchor undergoes chemical composition verification, casting inspection, dimensional inspection, heat treatment verification, mechanical property tests, proof load testing, visual inspection and non-destructive examination (MPI/UT where applicable). Suspension testing and permanent identification marking are performed prior to shipment. Material certificates and inspection reports can be supplied.

Application Standards
Suitable for fishing vessels, tugboats, barges, dredgers, inland cargo vessels, pontoons, floating docks, workboats and permanent mooring systems operating on sand, mud, clay and mixed seabeds. The fixed transverse stock makes the anchor suitable where long-term holding is required and compact recessed anchor pockets are not necessary.

Technical Specifications

• Product name: JIS stock anchor
• Model type: Stock anchor with fixed transverse stock
• Material: Marine-grade cast steel
• Nominal weight range: 500–20,000 kg (standard); larger sizes on request
• Applications: Fishing vessels, tugboats, barges, pontoons, workboats, dredgers, inland ships, permanent mooring systems
• Suitable seabeds: Mud, sand, clay, mixed seabeds
• Manufacturing standards: JIS, IACS UR A1, ISO 1704
• Certificates available: ABS, BV, CCS, DNV, LR, NK, KR, RINA, RS, RMRS
• MOQ: 1 Piece
• Packing options: Steel pallet, wooden crate, bulk packing
• Quality control: Chemical composition verification, casting inspection, dimensional inspection, heat treatment verification, mechanical property testing, proof testing, MPI/UT where applicable, suspension testing, permanent identification marking
