Anchor chain Guindeau Grade 30

steelzinc-platedshort-link

Product overview
Windlass Grade 30 5 Gallon Pail of Chain is a calibrated, welded low-carbon steel proof coil chain designed for marine anchor windlass systems and general anchoring and mooring applications. The chain is manufactured to ISO short-link dimensions for compatibility with ISO windlass gypsies and is supplied in a 5-gallon plastic pail for convenient storage, handling and transport. Available finishes: hot-dip galvanized, zinc plated or natural/self-color. Each production batch is proof load tested, dimensionally calibrated, weld inspected and visually inspected prior to shipment. The product is not intended for overhead or personnel lifting.

Key features

• Grade 30 welded proof coil chain
• ISO-calibrated short-link construction compatible with ISO windlass gypsies
• Supplied in a 5-gallon pail for easy handling and storage
• Finishes: hot-dip galvanized, zinc plated, or natural/self-color
• Proof load tested and subject to weld and dimensional inspection
• Intended for marine anchoring, mooring and general marine service

Dimensions and capacities
Wire Dia. (In.) | Inside Dimensions Length (In.) (Nom.) | Inside Dimensions Width (In.) (Min.) | Feet Per Pail | Net Wt. (Lbs.) | WLL (Lbs.) | Trade Size (In.)
0.279 | 1.000 | 0.507 | 141 | 106 | 1,300 | 1/4
0.342 | 1.100 | 0.507 | 92 | 103 | 1,900 | 5/16
0.404 | 1.230 | 0.620 | 63 | 101 | 2,650 | 3/8
0.512 | 1.500 | 0.820 | 36 | 94 | 4,500 | 1/2

Standards, packaging and testing
Product name: Windlass Grade 30 5 Gallon Pail of Chain Domestic Proof Coil ISO. MOQ: 100 meters. Package: 5-gallon plastic pail; steel pallet options for larger orders. Manufacturing standards: ISO 4565, DIN 766 (where applicable to calibrated dimensions), NACM Grade 30 proof coil requirements, applicable ASTM material specifications, ASME B30.26 and OSHA 1910.184 for general-purpose welded chains. Testing and quality control: proof load testing, dimensional calibration, weld inspection, visual inspection, mechanical property verification, chain pitch inspection, coating inspection for galvanized products, and production traceability for each batch.

Applications and maintenance
Suitable for anchor windlass systems on recreational boats, yachts, fishing vessels, pontoons, marina facilities, docks and general mooring and anchoring. Not for overhead lifting, crane lifting or personnel lifting. Maintenance: inspect regularly for corrosion, excessive wear, elongated links, cracked welds, deformation and coating damage. Rinse galvanized chains with fresh water after prolonged seawater exposure and inspect periodically. Remove from service if excessive wear, damaged welds or permanent deformation are detected.

Technical specifications

• Grade: Grade 30 proof coil chain (NACM / ASTM where applicable)
• Material: low carbon steel, electrically welded short-link construction
• Calibrated dimensions: ISO short-link dimensions for windlass compatibility
• Finishes: hot-dip galvanized, zinc plated, natural/self-color
• Packaging: 5-gallon pail; steel pallet options for bulk orders
• MOQ: 100 meters
• Quality control: proof load test, dimensional calibration, weld inspection, visual inspection, coating inspection, mechanical property verification, production traceability
• Intended use: anchoring, mooring and general marine service; compatible with ISO windlass gypsies
• Not for use: overhead lifting, crane lifting, or suspended/personal lifting
