Direct-operated solenoid valve IR-110-N1-2W2-wayfor waterhydraulic
Add to favorites
Compare this product
Characteristics
- Control
- direct-operated
- Ports/positions
- 2-way
- Medium
- for water, hydraulic
- Body
- plastic, in-line
- Other characteristics
- low-pressure, actuated, diaphragm, control
- DN
Max.: 150 mm
(5.906 in)Min.: 50 mm
(1.969 in)- Voltage
9 V, 24 V
- Pressure
Max.: 10 bar
(145 psi)Min.: 0.4 bar
(5.8 psi)
Description
Short description
The BERMAD Solenoid Controlled Valve IR-110-3W-X is a hydraulically operated, diaphragm-actuated 3-way control valve that opens and closes in response to an electric solenoid signal. Designed for irrigation and water-distribution applications, it belongs to the Series 100 range and features an hYflow 'Y' body for high flow efficiency.
Features
Typical applications
Additional features
Specifications / technical data
The BERMAD Solenoid Controlled Valve IR-110-3W-X is a hydraulically operated, diaphragm-actuated 3-way control valve that opens and closes in response to an electric solenoid signal. Designed for irrigation and water-distribution applications, it belongs to the Series 100 range and features an hYflow 'Y' body for high flow efficiency.
Features
- Hydraulic control valve
- Line-pressure driven for reliable On/Off operation
- Electrically actuated solenoid control (3-way)
- Engineered composite, industrial-grade construction
- Field-adaptable to a wide range of end connections
- Articulated flange connections to eliminate line bending and hydraulic stress
- Chemical- and cavitation-resistant materials
- hYflow 'Y' valve body with "Look Through" design
- Ultra-high flow capacity with low pressure loss
- Unitized "Flexible Super Travel" (FST) diaphragm and guided plug
- Smooth closing action
- Low actuation pressure requirement
- Prevents diaphragm erosion and distortion
- User-friendly maintenance
- Simple in-line inspection and service
Typical applications
- Automated irrigation systems
- Remote or elevated supply systems
- Distribution heads and centers
- Low supplied pressure irrigation systems
- Energy-saving irrigation systems
Additional features
- M : Flow stem (exclude sizes 4"L, 6"R)
- 5 : Plastic test point
- Z : Manual selector
- V3 : Victaulic PVC adaptors 3"
- V4 : Victaulic PVC adaptors 4"
Specifications / technical data
- Brand: BERMAD
- Model: IR-110-3W-X
- Series: 100 Series
- Product type: Solenoid Controlled Valve (On/Off, 3-way control)
- Control: 3-way control via electrically actuated solenoid
- Operation: Hydraulically operated, diaphragm actuated
- Body design: hYflow 'Y' valve body with "Look Through" design for ultra-high flow and low pressure loss
- Diaphragm & internals: Unitized FST diaphragm and guided plug for smooth closing and low actuation pressure
- Construction: Engineered composite, industrial grade; chemical and cavitation resistant
- End connections: Field adaptable; articulated flanges to eliminate line bending and hydraulic stresses
- Typical segment: Irrigation
- Page internal code: 26580
Catalogs
Model IR-11T-N1-2W
2 Pages
