Air particle counter A20

digitalcondensation

Overview
The A20 is an Airmodus condensation particle counter (CPC) engineered for accurate counting of individual aerosol particles from very low to high concentrations. Suitable for ambient air monitoring, aerosol research and regulatory measurements, the A20 counts particles larger than 10 nm (optionally configurable cut-off 3–23 nm) and offers high sensitivity and precision while maintaining a non-diluted sample flow.

Key features

• Counts individual particles up to 500,000 #/cm³
• Accurate particle counting across a wide concentration range
• Extremely low operational noise

All Airmodus CPCs feature

• Easy-to-use touchscreen interface
• Fully transparent algorithm
• Analog input and output
• Advanced pulse diagnostics
• BlockSafeTM flood prevention
• Included logging software

Applications
Automotive:

• EURO VI testing
• EURO 7 exhaust measurements
• EURO 7 brake dust measurements

Air quality:

• EN 16976 (formerly CEN/TS 16976)
• ACTRIS network monitoring
• CEN/TS 17434:2020

Other applications:

• Contamination studies
• Process monitoring
• Indoor air quality and clean environments

Available documents
Datasheet and brochure available for the A20 (see product documents).

Technical specifications

• Measured particle size: standard >10 nm (optional cut-off 3–23 nm)
• Maximum counting concentration: up to 500,000 particles/cm³
• Sample flow: non-diluted design for high statistics at low concentrations
• User interface: touchscreen
• Signal outputs: analog input/output available
• Diagnostics: advanced pulse diagnostics
• Flood protection: BlockSafeTM technology
• Software: logging software included
• Standards & compliance: meets ACTRIS and CEN requirements; A20-CEN on ACTRIS whitelist
• Typical use cases: ambient monitoring, aerosol research, regulatory measurements, contamination and process monitoring
