Airborne particle counter without display A20-CEN pgCPC

opticalcondensationmicrobial

Overview
Condensation Particle Counters (CPCs) detect and count ultrafine particles by growing nanoparticles in a saturator–condenser system to optically detectable sizes. The A20-CEN pgCPC is a CEN-compliant CPC using odorless, non-flammable Propylene Glycol (PG) as the working fluid. It delivers CEN 10 nm performance and provides higher nominal sample flow (1.05 lpm) compared with smaller models, improving counting statistics in odor-sensitive or butanol-restricted environments. The instrument can operate as a standalone monitor or as the detector CPC in A-SMPS systems.

Applications

• CEN-compliant ambient and laboratory monitoring where butanol is restricted
• Cleanroom and controlled-environment particle monitoring
• Aerosol research, SMPS detector, and bioaerosol studies

Features and benefits

• Safe working fluid: odorless, non-flammable Propylene Glycol (PG)
• High nominal sample flow: ~1.05 lpm (full flow through optics)
• Fully open calibration algorithm
• No catalytic vapour remover required
• Advanced signal diagnostics and instrument health monitoring
• CEN-compliant (EN 16976:2024)
• New inlet BlockSafe system; minimal cross-sensitivity with co-located gas monitors

Approvals & certifications

• EN 16976:2024 (CEN-compliant)
• ACTRIS equivalence demonstrated; formal approval pending

Technical specifications

• Model: A20-CEN pgCPC
• Particle size range: 10 nm – 2.5 μm *
• Cut-off (Dp50%): 10 nm ±1 nm; Dp90% < 20 nm
• Concentration range: 0 – 150,000 #/cm³ (single particle counting mode) **
• Aerosol inlet/sample flow: Nominal 1.05 lpm ±5% (full flow through optics)
• Response time: t95 < 1.15 s
• False counts: < 0.001 #/cm³
• Working fluid: Propylene Glycol (PG)
• Fluid consumption: 0.5–2 L per year (depending on operating conditions)
• Sample conditions: Pressure 75–105 kPa; Dew Point < 15°C ***
• Environmental conditions: Temperature 15–35°C; Pressure 75–105 kPa; RH 0–95%
• Communication: Analog out (BNC, 0–10 V), Pulse out (BNC), RS-232, Ethernet RJ45, USB type B
• Diagnostics: flow rate, saturator/condenser/optics temperature, liquid level, nozzle pressure, critical orifice pressure, laser current, pulse quality
• Fittings: inlet 1/4" SS tube; external vacuum 1/4" SS tube (built-in pump on request)
• Software: Airmodus MultiLogger (Windows 10+)
• External vacuum: 100–400 mbar at NTP (or <40% of inlet pressure)
• Power: external adapter 100–240 VAC 50/60 Hz, max 160 W; steady state 100 W; output 12 VDC 11.5 A
• Dimensions & weight: 260 × 230 × 400 mm (H × W × D), 8.5 kg
• Shipping: Temperature 0–40°C; RH <95% non-condensing; ship upright
• Notes: * Cut-off in mobility-equivalent diameter (silver particles). See calibration certificate. ** Calibrated range — CPC can measure higher concentrations but accuracy not individually verified. *** With high RH, use an aerosol dryer.

Downloads
Datasheet available for the A20-CEN pgCPC (PDF provided separately).
