Air airborne particle counter A30-CEN bCPC

digitalcondensationUSB

Overview
The A30-CEN bCPC is a condensation particle counter using n-Butanol as working fluid, designed for ambient air particle number monitoring and compliant with EN 16976:2024. It detects ultrafine particles by growing nanoparticles in a saturator–condenser system to optically detectable sizes and is suitable for field and laboratory use (4.9 kg).

Key features

• Concentration range: 0–500,000 #/cm³ (single particle counting mode)
• Dp50: 10 nm ±1 nm (CEN-compliant); Dp90 < 20 nm
• Nominal inlet/sample flow: 1.0 lpm / 0.2 lpm (bypass 0.8 lpm)
• Compact: 190 × 170 × 250 mm, 4.9 kg; typical power 40 W
• Open calibration algorithm
• Touchscreen user interface
• Advanced signal diagnostics and instrument health parameters
• Compatible with PSM 2.0 and dualCPC workflows; BlockSafe inlet system

Individual counting

• Calibration algorithms that offer complete transparency and traceability

Applications
Standalone ambient and indoor particle number monitoring, detector CPC in scanning mobility particle sizers (PSM/SMPS), detector in nano-CNC systems for sub-3 nm measurements, cleanroom monitoring and research applications.

Technical information
Particle size range: 10 nm – 2.5 μm *
Cut-off (Dp50%): 10 nm ±1 nm (CEN-compliant) & Dp90% < 20 nm
Concentration range: 0 – 500,000 #/cm³ (single particle counting mode) **
Aerosol inlet flow: Nominal flow 1.0 lpm
Aerosol sample flow: Nominal flow 0.2 lpm (bypass 0.8 lpm, critical orifice)
Response time: t95 < 1 s
False counts: < 0.001 #/cm³
Working fluid: n-Butanol (>99.5%)
Sample conditions: Pressure 75–105 kPa; Dew Point < 15°C ***
Environmental conditions: Temperature 15–35°C; Pressure 75–105 kPa; RH 0–95%
Communication: Analog out (BNC, 0–10 V), Pulse out (BNC), RS-232, Ethernet RJ45, USB type B. Optional: UIDEP, SD card
Diagnostics: Flow rate, saturator/condenser/optics temperature, liquid level, nozzle pressure, critical orifice pressure, laser current, pulse quality
Fittings: Inlet: 6 mm SS tube. External vacuum: 6 mm push-fit
Software: MultiLogger (Windows 10+)
External vacuum: 100–400 mbar at NTP (or <40% of inlet pressure)
Power requirements: External adaptor 100–240 VAC 50/60 Hz, max 100 W. Steady state: 40 W. Output: 12 VDC 11.5 A
Dimensions and weight: 190 × 170 × 250 mm (H × W × D), 4.9 kg
Shipping conditions: Temperature 0–40°C; RH <95% non-condensing. Ship upright.

Approvals & Certifications

• EN 16976:2024 (CEN-compliant)
• dualCPC compliant

Notes
* Cut-off reported as mobility-equivalent diameter (silver particles). 20 nm cut-off option available for A12 nCNC (butanol only). ** Calibrated range; higher concentrations measurable but not individually verified beyond calibrated range. *** At high RH, use an aerosol dryer; instrument includes active water removal system.
