Piston flow switch OF100 series

reedfor waterfor oil

Technical Data Piston type for high viscosity Fluid: Water, oil, other liquid available; Gases Flow Range:40~30,000 l/h (at Water); 1~740 Nm3/h (at Air) Accuracy: ±3% F.S, On request: ±2.5% F.S Size: 1/4" to 2-1/2" Connection Type: NPT, Flange type on request Working Limits: Temperature: -40℃ to +180℃ Working Pressure: 30kg/cm2 Option-100 kg/cm2 for 1" or less Option-200 kg/cm2 for 1-1/2" or bigger Protection Class: IP66, Explosion proof Housing Material: NS, CS, MS type-Aluminum Alloy; ES type-SS316 Lens Material: Safety glass Mounting: Vertical, Horizontal available Material: Wetted parts SS316; Teflon lining float for Gases application Alarm Switch: Micro switch, Inductive switch available
