Cylindrical anti-vibration mount FLEX-LOC

elastomerrubber

Description Cylindrical elastomer anti-vibration mounts for isolating equipment from structural vibration. Easy to install, flexible fixing resistant to oils, most solvents and ageing. Suitable for industrial applications where compact vibration isolation is required.

Advantages

• 80% reduction of vibrational energy transmitted from normal structural frequencies
• Simple and economical
• Easy to fix
• Light weight

Specifications / Design The design provides the following characteristics:

• The rubber works in compression (axial)
• The rubber works in shear (radial)
• The rubber works in compression/shear depending on the fixing method

Technical specifications

• Configuration: cylindrical
• Material: rubber, elastomer
• Static load: Max.: 28 daN; Min.: 1 daN
• Diameter: 9 mm, 12 mm, 15 mm, 18 mm, 24 mm (0.354 in, 0.472 in, 0.591 in, 0.709 in, 0.945 in)
