Round anti-vibration mount X

plasticepoxystainless steel

Description
Round marine shockproof holder from the X series by PAULSTRA. Radially mounted resilient mount with steel fixing elements and a stainless steel–epoxy sandwich that limits amplification and provides high fatigue resistance. Designed to maintain performance under repeated shocks and to provide vibratory and acoustic isolation for marine equipment.

Advantages

• Intrinsically stable under impact: returns the mass to its initial position without plastic deformation or residual buckling.
• The suspended mass can undergo several successive shocks without risk (assembly stability must be checked with respect to support positions and centre of gravity).
• Excellent vibratory and acoustic performance for marine applications.

Specifications (functional)

• Maintenance of the suspended mass in the absence of shock with vibratory and/or acoustic insulation capacity.
• In case of shocks: limitation of force and/or displacement to acceptable values.
• After shocks: return of the suspended mass to its initial position.

Technical characteristics / specifications

• Configuration: round
• Material: steel, stainless steel, epoxy, plastic
• Applications: marine
• Static load: Max.: 450 daN; Min.: 10 daN
• Diameter: Max.: 63.5 mm (2.5 in); Min.: 31.8 mm (1.252 in)
