Cylindrical anti-vibration mount

elastomerrubberring

Product overview
Elastomer rings and bushings designed as simple isolators for noise, shock and vibration control in industrial applications. Operating temperature range: -40°C to +83°C.

Advantages

• Effective reduction of airborne and structure-borne noise
• Absorb shocks and reduce transmitted vibrations
• Compact, economical solution for mounting and isolation
• Available in four stiffnesses for load capacities from 0.5 to 160 kg per isolator

Description
A ring assembled with its matching bushing forms a flexible interface that reduces noise and vibrations. Units can be installed in parallel to increase load capacity or stacked in series to increase deflection. Bushings may also be used in pairs (bushing-to-bushing) without rings where structure thickness or a more robust connection is required.

Technical specifications

• Material: elastomer (rubber)
• Operating temperature range: -40°C to +83°C
• Function: noise and vibration reduction, shock absorption
• Configuration: ring + bushing assembly forms a flexible interface
• Installation: parallel mounting for increased load capacity; series stacking for increased deflection
• Alternative: bushings can be paired without rings for thicker structures or more robust installations
• Models: four stiffnesses available for load capacities from 0.5 kg to 160 kg per isolator
