Round anti-vibration mount ISOFLEX®

metalrubberfor mobile devices

Description
An anti-vibration support designed for low static loads in compression and tension. The ISOFLEX® mount consists of two concentric metallic parts bonded together by a perforated rubber ring. The geometry and bonding provide approximately equal stiffness in all directions (equi-frequent mounting), making the mount suitable for applications requiring isotropic vibration isolation such as industrial machinery and mobile equipment.

Key features

• Configuration: round
• Material: metallic parts with bonded perforated rubber ring
• Applications: machines, mobile devices
• Other characteristic: bonded, perforated rubber ring connecting two concentric metallic parts
• Static load range: 0.25–6 daN
• Available diameters: 25.4 mm, 28 mm, 38.1 mm (1 in, 1.102 in, 1.5 in)
• Elasticity: approximately the same in all directions (equi-frequent mounting)

Technical specifications

• Configuration: round
• Material: two concentric metallic parts; bonded perforated rubber ring
• Applications: machines; mobile devices
• Static load: Min.: 0.25 daN
• Static load: Max.: 6 daN
• Diameter options: 25.4 mm, 28 mm, 38.1 mm (1 in, 1.102 in, 1.5 in)
• Elasticity: approximately the same in all directions (equi-frequent mounting)
