Hydraulic valve KVS series

flow controlpilotfor oil

Product overview
The KVS series steering valve controls flow to and from steering cylinders on wheel loaders and is intended for use in combination with an orbit roll or pilot valve.

Features

• Designed for systems using a fixed-displacement pump.
• Steering priority function ensures smooth steering operation and reduces energy consumption.
• Compatible with orbit roll or pilot valves for system flexibility.

Specifications

• Models: KVS25, KVS32
• KVS25 — Max. pressure: 21 MPa; Max. flow: 250 L/min
• KVS32 — Max. pressure: 32 MPa; Max. flow: 400 L/min

Applications

• Wheel loaders

Technical characteristics

• Product type: Steering valve to control flow to/from steering cylinders on wheel loaders (used with an orbit roll or pilot valve).
• Suitable for fixed-displacement pump systems.
• Priority steering function for improved control and energy efficiency.
• Available models cover a range of pressures and flows to match machine sizes.
