Oil relief valve PV48 series

for hydraulic systemspilot-operatedhydraulic

Overview
PV48 series is a pressure-reducing pilot valve designed to control multiple spool control valves and to adjust the tilting angle of variable displacement pumps simultaneously. The series includes PV48K (joystick type) and PV48M (compact joystick) models suited for construction and mobile machinery hydraulic systems.

Features

• Operational torque can be reduced according to customer requirements (patent registered), enabling fine control.
• Reduced pressure drop and quick response for improved control sensitivity (US Pat. No. 6,125,886).

Specifications

• Model: PV48 series (PV48K, PV48M)
• Type: Pressure-reducing pilot valve
• Max. inlet pressure: 6.9 MPa
• Output pressure range: 0–2.9 MPa
• Rated flow: PV48K 20 L/min; PV48M 15 L/min
• Operation: PV48K joystick type; PV48M compact joystick type

Applications

• Excavators
• Wheel loaders
• Backhoe loaders
• Track loaders
• Dump trucks
• Crawler drills / pile drivers
• Cranes (crawler / rough terrain)
• Telehandlers
• Forestry equipment

Technical specifications

• Designed for integration with multiple control valves and variable displacement pumps.
• Patent-protected torque adjustment option to tailor operator feel.
• Typical OEM use in mobile hydraulic equipment; consult manufacturer for mounting and interface details.
