Band saw ABS 560 L

horizontalfor metalsfor large products

Product overview
The ABS 560 L is a fully automatic horizontal band saw designed for precise straight cutting of large and heavy workpieces. A rigid dual-column frame and high-quality linear guides ensure structural stiffness. Machine functions — saw frame feed, stepless blade speed adjustment and hydraulic clamping — are managed from the central control panel. The automatic material feed operates hydraulically without electronic programming while maintaining high repeatability and dimensional accuracy.

Highlights

• Rigid dual-column frame for torsional stiffness
• Hydraulic automatic material feed with hardened guide rollers
• Hydraulic workpiece clamping
• Optical workpiece height detection for optimized empty runs
• Feed roller table 1.2 m (standard)

Technical specifications

• Working area: Working height: 585 mm
• Cutting capacities: 0° (flat) up to 600 mm x 560 mm; 0° (round) up to 560 mm; 0° (square) up to 560 mm x 560 mm
• Cutting speed (infinitely variable): 15 m/min – 120 m/min
• Stop length: 500 mm
• Feed accuracy: 0.5 mm
• Drive power: main drive 4 kW; hydraulic pump 1.1 kW; feed 0.55 kW
• Dimensions (L x W x H): 3.25 m x 1.4 m x 2.1 m
• Weight: 2,100 kg
• Blade size: 6,000 mm x 41 mm x 1.3 mm

Product details

• Torsionally rigid steel machine frame with quality linear guides
• Proven automatic feed system with hardened workpiece guide rollers and hydraulic clamping
• Advanced hydraulic saw-frame feed with pressure control for reduced machining times and infinitely variable feed speed and cutting pressure
• All essential controls clearly labeled and accessible at the control valves
• Optical height registration allows rapid empty runs and automated transition to work feed, limiting saw-frame travel to reduce operator workload

Standard equipment

• Saw band
• Workpiece counter
• Band break control
• Coolant system
• Hydraulic clamping
• Mechanical blade tensioning with hydraulic pressure gauge
• Feed roller table 1.2 m
• Linear stop
• Operating manual

Optional equipment

• 3 m roller extension
• Chip conveyor
• Hydraulic blade tensioning
• Minimum quantity lubrication (MQL)
• Laser pointer
• Clamping force control at operator panel
• Micro spray cooling system for band saws 400–810

Technical data summary

• Model: ABS 560 L
• Working height: 585 mm
• Cutting capacity (flat): up to 600 x 560 mm
• Cutting capacity (round): up to 560 mm
• Cutting speed range: 15–120 m/min (infinitely variable)
• Feed accuracy: 0.5 mm
• Main drive: 4 kW; hydraulic pump: 1.1 kW; feed: 0.55 kW
• Overall dimensions (L x W x H): 3.25 m x 1.4 m x 2.1 m
• Weight: 2,100 kg
• Blade dimensions: 6,000 mm x 41 mm x 1.3 mm
