Band saw HB 810 L

horizontalfor steelfor cast iron

Overview
The HB 810 L is a semi-automatic horizontal bandsaw from the HB-L series designed for heavy cutting of steel, cast iron and similar materials. The rigid dual-column construction with oversized linear guides reduces vibration and delivers accurate, repeatable cuts. Stepless blade speed, finely adjustable hydraulic feed and a swiveling vise enable controlled machining across different profiles and materials.

Key features

• Dual-column design with heavy-duty linear guides
• Semi-automatic sawing cycle with optical stroke-height detection
• Hydraulic workpiece clamping with 45° swivel for mitre cuts
• Infinitely variable blade speed and hydraulic feed with PAS pressure regulation
• Manometer for precise blade tensioning and removable coolant reservoir for maintenance

Product details
Built for precise sawing of sections and solid material (steel, aluminium, cast iron) in production and workshop environments. Easy setup, low-maintenance drives and user-friendly controls allow fast changeovers and consistent output.

• Stepless cutting speed: 15–120 m/min
• Powerful, low-maintenance motors for continuous operation
• Hydraulic clamping standard on all models; optional top clamping available
• Pressure gauge ensures correct blade tension to extend blade life
• Removable coolant tank for simplified cleaning and maintenance
• Mono-frame saw head running on large linear guides for high stiffness

Standard equipment

• Bimetallic band saw blade
• Hydraulic part clamping (swiveling vise)
• Automatic stroke height adjustment with optical sensor
• PAS pressure adjusting system
• Coolant system with removable reservoir
• Feed roller table 1 m and operating manual

Optional equipment

• 3 m roller table for HB 810 L (SKU: 251837) / Motorized 3 m roller table (SKU: 251838)
• Hydraulic top clamping for HB 810 L (SKU: 251835)
• Turn table for HB 810 L (SKU: 251840)
• Chip conveyor for HB 810 L (SKU: 253893)
• Hydraulic saw blade tensioning for HB 810 L (SKU: 253896)
• Minimum quantity lubrication (MQL) (SKU: 253719) and laser pointer (SKU: 253753)
• Clamping force control at operator panel (SKU: 253899) and micro spray cooling for band saws 400-810 (SKU: 254015)

Technical specifications — Cutting capacities
Cutting capacity 0° (round): 810 mm
Cutting capacity 0° (square): 810 mm
Cutting capacity 0° (flat) (length x width): 790 mm x 850 mm
Cutting capacity 45° (flat) (length x width): 480 mm x 790 mm
Cutting capacity 45° (round): 480 mm
Cutting capacity 45° (square): 810 mm
Cutting speed: 15 m/min - 120 m/min

Technical specifications — Drive capacity
Motor rating main drive: 5.5 kW
Motor rating hydraulic pump: 1.5 kW
Motor rating coolant pump: 0.12 kW

Technical specifications — Measures and weights
Blade dimensions: 8,200 mm x 41 mm x 1.3 mm
Overall dimensions (length x width x height): 3.9 m x 1.4 m x 2.72 m
Weight: 3,050 kg

Applications

• Heavy-duty cutting in metalworking, fabrication, maintenance workshops and component manufacturing
