Band saw HB 460 L

horizontalfor metalssemi-automatic

Overview The semi-automatic horizontal band saws of the HB-L series are built for heavy-duty cutting of steel, cast iron and other solid materials. Rigid dual-column construction with large linear guides reduces vibration and ensures consistent cutting accuracy. Fine-adjustable blade feed, stepless blade speed control and a swiveling hydraulic vise enable flexible machining.

Highlights

• Dual-column design with large linear guides
• Semi-automatic operation with optical stroke height sensor
• 45° swiveling vise for mitre cuts
• PAS pressure-regulated hydraulic feed for adjustable cutting force
• Short setup time and removable coolant tank for easy maintenance

Technical specifications
Working area
Working height: 585 mm

Cutting capacities
0° (round): 460 mm
0° (square): 460 mm
0° (flat, L x W): 650 mm x 460 mm
45° (round): 340 mm
45° (square): 340 mm
45° (flat, L x W): 340 mm x 460 mm
Cutting speed: 15 m/min - 120 m/min

Drive capacity
Main drive: 4 kW
Hydraulic pump: 0.55 kW
Coolant pump: 0.12 kW

Measures and weights
Blade dimensions: 5,200 mm x 41 mm x 1.3 mm
Max blade length: 5,750 mm
Overall dimensions (L x W x H): 3 m x 1.2 m x 1.8 m
Weight: 1,520 kg

Product details

• Designed for precise sawing of profiles and solid material such as steel and aluminium
• Infinitely variable cutting speeds (model dependent)
• Powerful, low-maintenance motors for high reliability
• Hydraulic workpiece clamping as standard
• Pressure gauge for accurate blade tensioning to extend blade life
• Removable coolant tank for simplified maintenance
• Mono-frame saw frame travelling on large linear guides for rigidity
• Control valve labeled for material types to ease operation
• Optical workpiece height detection enabling automated rapid-feed empty runs

Standard equipment

• Bimetallic band saw blade
• Mechanical blade tensioning with hydraulic pressure gauge
• Hydraulic part clamping
• Automatic stroke height adjustment (optical sensor)
• Feed roller table 1 m
• PAS pressure-regulated feed system
• Coolant system
• Operating manual

Optional equipment (examples)

• 3 m roller table
• Motorized 3 m roller table
• 3 m / 6 m roller table with length stopper & digital readout
• Hydraulic top clamping
• Chip conveyor
• Turn table
• Hydraulic blade tensioning
• Minimum quantity (micro spray) cooling system
• Laser pointer
• Clamping force control at operator panel

Technical data summary

• Model: HB 460 L
• Working height: 585 mm
• Max cutting capacity round (0°): 460 mm
• Max cutting capacity flat (0°): 650 x 460 mm
• Cutting speed range: 15–120 m/min
• Main drive power: 4 kW
• Blade dimensions: 5,200 x 41 x 1.3 mm
• Overall dimensions approx.: 3 m x 1.2 m x 1.8 m
• Weight approx.: 1,520 kg
