Rotary laboratory stirrer LMX series

digitalfor liquidsfor vessels

Overview
High-speed rotary laboratory and pilot-plant mixers for fluid processing. Available in 25 L (LMX25) and 75 L (LMX75) bowl sizes, manufactured in high-polished stainless steel and designed for laboratory R&D and pilot production where controlled, repeatable high-shear mixing is required.

Key features

• Available in 25 L (LMX25) and 75 L (LMX75) pilot-plant sizes
• Infinitely variable impeller speed ranges for process flexibility
• Automatic mixing cycles for repeatable results
• Optional impeller water cooling for temperature control
• Computer version with color LCD touchscreen controls
• User-friendly software enabling operation, data logging and printing of graphics via PC
• High-polished stainless steel construction for easy cleaning and regulatory compliance

Performance table
Model | LMX25 | LMX75
Mixer bowl volume (L) | 25 | 75
Impeller speed (rpm) | 500–2,500 | 300–1,300
Motor power (kW) | 11 | 4

Technical specifications

• Models: LMX series (LMX25, LMX75)
• Mixer bowl volume: 25 L (LMX25), 75 L (LMX75)
• Impeller speed range: 500–2,500 rpm (LMX25), 300–1,300 rpm (LMX75)
• Motor power: 11 kW (LMX25), 4 kW (LMX75)
• Construction material: high-polished stainless steel
• Impeller water cooling: optional
• Control options: manual and computer version with color LCD touchscreen
• Software: proprietary user-friendly software with data export and printing via PC
• Functionality: infinitely variable speed control and automatic mixing cycles for consistent processing

Characteristics

• Type: rotary
• Display: digital
• Applications: liquid processing, mixing, vessel mixing for laboratory and pilot production
• Other characteristics: stainless steel, high-speed, variable-speed, digital control, color LCD, large capacity, optional cooling
• Rotational speed (note): Min. 300 rpm; Max. 2,500 rpm

Characteristics / technical specifications

• Series: LMX (LMX25, LMX75)
• Bowl volumes: 25 L and 75 L
• Speed ranges: LMX25 = 500–2,500 rpm; LMX75 = 300–1,300 rpm
• Motor power: LMX25 = 11 kW; LMX75 = 4 kW
• Construction: polished stainless steel
• Cooling: optional impeller water cooling
• Controls: manual or computer with color LCD touchscreen
• Software: PC-compatible for operation, data logging and graphics printing
• Functionality: variable speed and automatic cycles for reproducibility
