3-roll calendering machine LCCR series

3 drive rollerselectric

Description
Large combined chill-roll and calendering attachments designed for web handling and film finishing. Roll diameters up to 250 mm and available roll widths up to 1200 mm. Heavy-duty hydraulic lay-on is provided for both lower and upper rolls against the center roll. Each roll features individual tempering (water or oil) and is driven by its own servo motor. The roll stack includes a motorized tilting mechanism allowing positioning from horizontal to vertical and inclines up to 45°, facilitating integration with downstream equipment.

Key features

• Roll diameters up to 250 mm
• Heavy-duty hydraulic lay-on for lower and upper rolls against center roll
• Available roll widths up to 1200 mm
• Individual roll tempering: water tempering or oil heating per roll
• Motorized tilting mechanism: positions from horizontal to vertical, inclines up to 45°
• Individual servo motor drives for each roll

Models / Overview table
Models: LCCR-300-SR | LCCR-350-SR | LCCR-500-HD | LCCR-600-HD | LCCR-700-HD | LCCR-1200-HD
Roll width (mm): 350 | 400 | 500 | 600 | 700 | 1200
Max. film width (un-trimmed) (mm): 300 | 350 | 450 | 550 | 650 | 1100
Max. Die width (mm): 350 | 400 | 500 | 600 | 700 | 1200
Roll diameter, all 3 rolls (mm): 145 | 145 | 175 | 175 | 200 | 200
Gap fine adjustment (mm): 9,100/90 | 22,500/90 | 0.75 | 0.75 | 0.75 | 0.75
Take-off speed (m/min): 0.37 | 0.37 | 3 x 1 | 3 x 1 | 3 x 1.5 | 3 x 2

Technical specifications

• Series: LCCR
• Available models: LCCR-300-SR, LCCR-350-SR, LCCR-500-HD, LCCR-600-HD, LCCR-700-HD, LCCR-1200-HD
• Roll width (mm) by model: 350 / 400 / 500 / 600 / 700 / 1200
• Max. film width (un-trimmed) (mm) by model: 300 / 350 / 450 / 550 / 650 / 1100
• Max. Die width (mm) by model: 350 / 400 / 500 / 600 / 700 / 1200
• Roll diameter (all 3 rolls) (mm) by model: 145 / 145 / 175 / 175 / 200 / 200
• Gap fine adjustment (mm) by model: 9,100/90 / 22,500/90 / 0.75 / 0.75 / 0.75 / 0.75
• Take-off speed (m/min) / motor configuration by model: 0.37 / 0.37 / 3 x 1 / 3 x 1 / 3 x 1.5 / 3 x 2
• Individual roll tempering: water or oil heating per roll
• Hydraulic lay-on system for upper and lower rolls
• Motorized tilting mechanism for roll stack positioning (horizontal to vertical, incl. 45°)
• Individual servo motor drives for each roll
