Single screw screw extruder Maxi26

co-rotating twin-screwcompoundingfor thermoplastics

Product overview
Modular co-rotating twin-screw extruders with clamshell barrel inserts. Available screw diameters: 12, 16, 20 and 26 mm. Single-screw elements mounted on hexagonal shafts enable rapid reconfiguration for compounding and reactive extrusion. The Maxi26 Compounder variant offers a 22 kW drive motor and a maximum screw speed up to 1200 RPM for increased throughput.

Performance data

• Screw Speed (Standard): 0 to 800 RPM
• Screw Speed (Maxi26 Compounder): 0 to 1200 RPM
• Motor Power (Standard): 15 kW
• Motor Power (Maxi26 Compounder): 22 kW
• Maximum torque at 600 RPM: 2 x 90 Nm
• Specific Torque: 9.8 Nm/cm3
• Max barrel temperature (Standard): 400°C
• Total max power for 40 L/D (Standard): 35 kW
• Total max power for 40 L/D (Maxi26): 42 kW
• Approx. max. output (LDPE) (Standard): 64 kg/hr
• Approx. max. output (LDPE) (Maxi26): 80 kg/hr

Technical specifications

• Screw diameters: 12, 16, 20, 26 mm
• Configuration: Modular co-rotating twin-screw with clamshell barrel inserts
• Screw elements: Single elements on hexagonal shafts for rapid reconfiguration
• Max barrel temperature (Standard): 400°C
• Specific torque: 9.8 Nm/cm3

Optional equipment

• Hopper feeders
• Vacuum pump with multiple vent outlets on the barrel
• Twin-screw side feeder
• Liquid feeders
• Quick screen changer

Typical applications

• Thermoplastics compounding and masterbatch production
• Reactive extrusion and compounding with additives
• Small batch production and R&D

Features / technical specifications

• Number of screws: co-rotating twin-screw, single-screw elements available
• Applications: compounding, reactive extrusion
• Treated material: thermoplastics
• Other characteristics: modular design, clamshell barrel for easy access
• Output: 64 kg/h (Standard), 80 kg/h (Maxi26) — 141.0958 lb/h, 176.3698 lb/h
• Screw diameter: 26 mm (1 in)
• Power: 15 kW (Standard), 22 kW (Maxi26)
