Twin screw screw extruder COMBI

for thermoplastics

Description
The new 26 mm COMBI twin-screw extruder features selectable co- and counter-rotating operation with a gear selector for quick changeover. The machine uses a modular clam-shell barrel design with barrel sections of 4 D (104 mm) each. Standard drive power is 15 kW with maximum screw speeds up to 800 RPM (co-rotating) and 400 RPM (counter-rotating). The unit is equipped with a redesigned high-torque gearbox including additional shaft-supporting gears and a direct-driven gear pump for closed-loop forced oil lubrication and cooling.

Table - Twin Screw Extruders for Thermoplastics
Twin Screw Extruders for Thermoplastics | Standard Co-Rotating | PVC Version Counter
Screw Speed (RPM) | 0 to 800 | 0 to 400
Motor Power (kW) | 15 kW | 15 kW
Maximum torque at 600 RPM | 2 x 90 Nm | 2 x 90 Nm
Specific Torque Nm/cm3 | 9.8 | 9.8
Max barrel temp.(Standard) | 400°C | 400°C
Approx. max. output | 65 kg/hr (LDPE) | 50 kg/hr (Soft PVC pellets)

Technical specifications

• Type: COMBI twin-screw extruder with co- and counter-rotating capability
• Screw diameter: 26 mm (1 in)
• Gear selector for easy changeover between co- and counter-rotation
• Modular clam-shell barrel construction; each barrel section length = 4 D (104 mm)
• Drive power (standard): 15 kW
• Maximum screw speed: up to 800 RPM (co-rotating), up to 400 RPM (counter-rotating)
• Maximum torque at 600 RPM: 2 x 90 Nm
• Specific torque: 9.8 Nm/cm3
• Maximum barrel temperature (standard): 400°C
• Approx. maximum output: ~65 kg/hr (LDPE); ~50 kg/hr (soft PVC pellets)
• Re-designed high-torque gearbox with additional shaft-supporting gears
• Direct-driven gear pump for closed-loop forced oil lubrication and cooling

Caractéristiques / Spécifications techniques

• Number of screws: twin screw
• Treated material: for thermoplastics
• Output: 50 kg/h, 65 kg/h (110.2311 lb/h, 143.3005 lb/h)
• Screw diameter: 26 mm (1 in)
• Maximum speed: Min.: 0 rpm (0 rad.min-1); Max.: 800 rpm (5,027 rad.min-1)
• Power: 15 kW (20.39 hp)
• Maximum torque at 600 RPM: 2 x 90 Nm
• Specific torque: 9.8 Nm/cm3
• Max barrel temp. (Standard): 400°C
• Approx. max. output: 65 kg/hr (LDPE) ; 50 kg/hr (Soft PVC pellets)
• Gear selector for quick changeover between co- and counter-rotation
• Modular clam-shell barrel (sections = 4 D / 104 mm)
• High-torque gearbox redesign and direct-driven gear pump for closed-loop forced oil lubrication and cooling
