Anchor chain Windlass Grade 30

towingsteelcarbon steel

Product Overview
Windlass Grade 30 5 Gallon Pail of Chain. Electronically welded proof coil chain with hot‑dip galvanized finish for corrosion protection. Meets or exceeds NACM and ASTM standards. Not for overhead lifting; never exceed the published Working Load Limit (WLL).

Introduction
Grade 30 proof coil chain is manufactured from low carbon steel and serves as a general utility chain suitable for applications such as anchoring and mooring on small craft, farm use, log and tow operations, and switch chain tasks.

Caution

• Do not use for overhead lifting.
• DO NOT EXCEED THE WORKING LOAD LIMIT (WLL).

Parameter (Definitions)

• Grade of Chain: NACM (National Association of Chain Manufacturers) and ASTM (American Society for Testing and Materials) classify chains by grade. Higher grades provide higher working load limits for the same chain size.
• Working Load Limit (WLL): The maximum working load that should be applied in direct tension to an undamaged, straight length of chain.
• Proof Test: The minimum tensile force applied during manufacturing under a steadily increasing direct tension. Proof tests verify manufacturing integrity and are not criteria for service design.
• Minimum Breaking Force: The minimum tensile force at which test samples fractured under increasing direct tension during manufacture. Breaking force values are acceptance tests and are not guarantees for service conditions.
• Overhead Lifting: Lifting that elevates a freely suspended load to a position where dropping it could cause injury or damage; Grade 30 chain is not rated for such lifting.

Table — Chain Dimensions and Capacities
Wire Dia. (In.) | Inside Length (Nom.) | Inside Width (Min.) | Feet Per Pail | Net Wt. (Lbs.) | WLL Lbs. | Trade Size (In.)
0.279 | 1.000 | 0.507 | 141 | 106 | 1,300 | 1/4
0.342 | 1.100 | 0.507 | 92 | 103 | 1,900 | 5/16
0.404 | 1.230 | 0.620 | 63 | 101 | 2,650 | 3/8
0.512 | 1.500 | 0.820 | 36 | 94 | 4,500 | 1/2

Standards & Packaging

• Standard: Windlass Grade 30 5 Gallon Pail of Chain Domestic Proof Coil ISO
• MOQ: 100 Meters
• Package: Carton + Steel Pallet

Technical characteristics / Specifications

• Product family: Windlass (Grade 30 proof coil chain)
• Construction: Electronically welded proof coil chain
• Material: Low carbon steel
• Finish: Hot‑dip galvanized for corrosion protection
• Standards compliance: Meets or exceeds NACM and ASTM standards
• Intended uses: Anchoring and mooring on small craft, farm, log, tow and switch chain (general utility)
• Restrictions: Not for overhead lifting; never exceed published Working Load Limit (WLL)
• Available trade sizes and corresponding WLL and weights: see table above
• MOQ: 100 meters
• Packaging: Carton plus steel pallet
