DIN workpiece clamping chuck 3205-8for turning applicationsstandardself-centering
Add to favorites
Compare this product
Characteristics
- Machine mount
- DIN
- Application
- for turning applications
- Other characteristics
- self-centering, standard
- Number of jaws
- 3-jaw
- Clamping range
8 in
Description
Product overview
3-jaw self-centering scroll chuck for lathe applications. Model 3205-8" with cast iron body and plain back mount per DIN 6350. Supplied with hard 2-piece jaws and featuring a through-hole for bar work. Accuracy class: standard.
Identifiers
SKU: 353205550601
Sku USA: 7-800-0800
Product details
Technical specifications
3-jaw self-centering scroll chuck for lathe applications. Model 3205-8" with cast iron body and plain back mount per DIN 6350. Supplied with hard 2-piece jaws and featuring a through-hole for bar work. Accuracy class: standard.
Identifiers
SKU: 353205550601
Sku USA: 7-800-0800
Product details
- Product type: 3205-8
- Size: 8"
- Number of jaws: 3
- Type of jaws: Hard 2-piece jaws
- Mounting: Plain back mount (DIN 6350)
- Measurement unit: inch
- Body material: Cast iron
- Accuracy class: Standard
- Through-hole: Yes
- Increased clamping force: No
- Chucks with large through-hole: No
Technical specifications
- SKU: 353205550601
- Sku USA: 7-800-0800
- Intended use: Lathe clamping for bar and turned parts
