DIN workpiece clamping chuck 3205-250

for turning applicationsfor external turningself-centering

Overview
3-jaw self-centering scroll chuck 3205-250 with cast iron body and plain back mounting (DIN 6350). Nominal size 250 mm. Designed for turning and general machining operations requiring a through-hole.

Product information

• SKU: 353205060300
• Alternate SKU: 353205600801
• SKU USA: 7-800-2500
• Promo: No
• Size: 250 mm
• Product type: 3205-250
• Number of jaws: 3
• Type of jaws: Hard 2-piece scroll jaws
• Mounting: Plain back mount (DIN 6350)
• Measurement unit: metric
• Body material: Cast iron
• Accuracy class: Standard
• Through-hole: Yes
• Increased clamping force: No
• Chucks with large through-hole: No

Technical specifications

• Function: Self-centering scroll chuck (3-jaw)
• Material: Cast iron (body)
• Mounting standard: DIN 6350, plain back
• Nominal size: 250 mm
• Model / product type: 3205-250
• Number of jaws: 3
• Jaws: Hard 2-piece scroll jaws
• Measurement unit: Metric (mm)
• Through-hole: Yes
• Accuracy: Standard class

Applications

• Used on lathes for external turning and general clamping tasks
• Suitable for workpieces requiring a through-hole for bar feeding or coolant passage
• Complies with DIN 6350 plain back mounting for compatibility with standard lathe spindles
