LCD monitor AMG-15IPTP01T1

resistive touch screenLED backlightPCAP touchscreen

Product overview
This 15-inch industrial resistive touch LCD monitor AMG-15IPTP01T1 is intended for flush rear mounting in equipment and control panels. It offers 1024x768 resolution, 400 nits brightness and an extended operating temperature range for continuous industrial use.

Key features

• Touchscreen options: PCAP, resistive and other variants available.
• Rear VESA mounting holes for flush installation.
• LED backlight with 400 nits brightness and 700:1 contrast ratio.
• Multiple signal inputs: VGA, DVI, DC 2.0 and audio.
• Designed for 24/7 continuous operation; operating range -30～85℃.

Typical applications

• Treadmills and fitness equipment
• Industrial machinery and HMIs
• Railway and transportation panels
• Control cabinets and kiosks

Specification
Screen Size: 15"
Active Display Area (mm): 304.128(H) x 228.096(V)
Pixel Pitch (mm): 0.297(H) x 0.297(V)
Display Mode: Normally white
Display Resolution (pixel): 1024x768
Contrast Ratio: 700:1
Display Color: 16.2M
Brightness: 400nits
Backlight: LED
Viewing Angles (CR=10): 160(H) x 140(V)
Response Time (Typ.Tr+Tf): 8ms
Touch Screen: Resistive
Signal Connector: VGA/DVI/DC 2.0/Audio
Power Input: DC 12V
Operating Temperature: -30～85℃
Storage Temperature: -30～85℃
Relative Humidity: 5(%RH)～90(%RH)

Technical specifications

• Screen Size: 15"
• Active Display Area (mm): 304.128(H) x 228.096(V)
• Pixel Pitch (mm): 0.297(H) x 0.297(V)
• Display Mode: Normally white
• Display Resolution (pixel): 1024x768
• Contrast Ratio: 700:1
• Display Color: 16.2M
• Brightness: 400nits
• Backlight: LED
• Viewing Angles (CR=10): 160(H) x 140(V)
• Response Time (Typ.Tr+Tf): 8ms
• Touch Screen: Resistive
• Signal Connector: VGA/DVI/DC 2.0/Audio
• Power Input: DC 12V
• Operating Temperature: -30～85℃
• Storage Temperature: -30～85℃
• Relative Humidity: 5(%RH)～90(%RH)
