Slewing drive S-I-O-0229

Spur gear slew drives are installed horizontally on special equipment. Operating conditions: large tilting moment, high speed, large inertias, large impact load. According to the above working conditions, the slewing bearings are designed in accordance with large tilting moment and adopt a small clearance and high precision design to ensure stable rotation of the slew drives at high speeds. The teeth adopt surface induction hardening to ensure large output torque and wear resistance. The tooth core is soft, it has good impact resistance and is suitable for large inertia and large impact load. The housings are made of nodular cast iron QT450-10, which has excellent mechanical properties, high stability, wear resistance and shock resistance. The housing surfaces are powder-coated/spray treatment, rust-proof and beautiful. Before spraying, phosphating treatment is carried out to improve anti-rust ability and adhesion of spray. The input flanges are designed and manufactured according to the dimensions of the customer’s motor output. The customers can directly connect the motors, providing customers with great convenience, reducing connecting parts, increasing stability, saving space, reducing the dimensions of the whole machine and also reducing costs.
